Fine Oven Programmable 91L Overview
The Fine Oven Programmable 91L (model DH412) from Yamato Scientific is a 91-liter mechanical convection oven engineered for temperature characteristic testing, with an operating range of ambient +15 to 360°C. LabSupplies.com, an authorized dealer, supplies this unit as a genuine Yamato Scientific product.
Precise temperature stability and uniformity anchor the DH412, while an adjustable air-speed function lets technicians tune circulation to the load. An exhaust damper drives quick chamber exhaust and cooling, and dedicated exhaust and cable ports support thermocouple routing and process venting.
Constructed from chrome-free electrogalvanized carbon steel with a chemical-proof baked-on exterior coating and a stainless steel interior chamber, the DH412 runs on 220V power. Built in Japan, the oven measures 49 × 33 × 43 inches and weighs 365 lbs. Manufacturing is certified to ISO 9001:2015 and ISO 14001:2015.
Key Features
- Programmable control: enhanced program operation supports up to 99 steps, 99 patterns, and a repetitive operation function for complex multi-stage profiles.
- Adjustable air speed: standard-equipped airflow control tunes circulation to match the load and improve uniformity.
- Improved control panel: upgraded visibility and operability simplify setup, with onboard displays for power consumption, CO₂ emission, and a heat timer.
- Fan motor error detection: built-in monitoring flags fan motor faults to protect the chamber and the process.
- Exhaust damper: the damper enables rapid chamber exhaust and cooling between runs.
- Access ports: dedicated exhaust and cable ports route sensors and venting without compromising the seal.
How to Choose the Right Fine Oven
Selecting a fine oven comes down to matching chamber size, achievable temperature, control sophistication, and site power to your testing workflow. Use the criteria below to confirm the DH412 fits your application .
- Capacity: the 91 L chamber sets how many samples or how large a fixture you can process per run; size it to your typical batch.
- Temperature range: an ambient +15 to 360°C span covers most characteristic and curing tests; verify your setpoints fall inside it.
- Control type: programmable operation with 99 steps and 99 patterns suits multi-stage ramp-and-soak profiles rather than single fixed setpoints.
- Voltage: the DH412 requires 220V; confirm a matching circuit is available at the install location.
- Footprint and weight: at 49 × 33 × 43 inches and 365 lbs, plan bench or floor space and verify delivery access.
- Safety features: fan motor error detection adds protection for unattended or extended runs.
Specifications
| Specification | Detail |
|---|---|
| Capacity | 91 L |
| Max Temperature | 360°C |
| Voltage | 220V |
| Circulation Method | Forced air circulation and ventilation |
| Temperature Control System | PID-Z control |
| Sensor | Double K-thermocouple |
| Interior Material | Stainless steel |
| Special Features | Variable air-flow function; power/CO₂ monitoring; up to 99 program steps |
| Temperature Accuracy | ±0.2°C (at 360°C) *2 |
| Temperature Distribution | ±2.5°C (at 360°C) *2 |
| Heater | Stainless pipe heater with fan, 2.7 kW |
| Max. Temperature Reaching Time | Approx. 50 min |
| Operating Temperature Range | ambient +15 to 360°C *1 |
| Material | Chrome-free electrogalvanized carbon steel sheet metal, finished in chemical-proof, baked-on coating (exterior) Stainless steel sheet metal (interior) |
| Country of Origin | Japan |
| GTIN (Barcode) | 797059926718 |
| Shipping Weight | 365 lbs |
| Dimensions (L × W × H) | 49 × 33 × 43 in |
| Component Size | 91 L |
*1 No-load operation of bath only; maximum temperature varies with circumstances and operating conditions. *2 Measured under ambient temperature 23°C ±5°C, humidity 65%RH ±20%, per Yamato Scientific test conditions.
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| DH-412 | EA | EA |
Documentation
More in This Series
- Fine Oven Programmable 91L
- Fine Oven Programmable 216L
- Fine Oven Programmable 512L 3 Phase
- Fine Oven Programmable 1000L 3 Phase
- Fine Oven Programmable 216L
- Fine Oven Programmable 512L 3 Phase
- Fine Oven Programmable 1000L 3 Phase
- High Temperature Fine Oven Programmable 216L 3 Phase
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so the DH412 ships as a genuine unit backed by the manufacturer warranty. Our team supports the specification and configuration questions procurement and lab managers raise before purchase.
- Authorized Yamato Scientific dealer: genuine equipment with full manufacturer warranty.
- In stock: the DH412 is available now, ready to order.
- Ships from USA inventory: domestic fulfillment shortens lead time.
- Lab-equipment specialists: dedicated support for technical and spec questions.
Frequently Asked Questions
What is the maximum operating temperature of the Yamato DH412 fine oven?
The DH412 reaches 360°C, with an operating range of ambient +15 to 360°C. This span covers most temperature characteristic and curing tests.
What is the chamber capacity and overall footprint of the DH412?
The DH412 offers a 91 L chamber. External dimensions are 49 × 33 × 43 inches and the unit weighs 365 lbs, so plan install space and delivery access accordingly.
What voltage does the DH412 require?
The DH412 runs on 220V. Confirm a matching 220V circuit is available at the install location before ordering.
What are the chamber and exterior built from?
The interior chamber is stainless steel sheet metal. The exterior uses chrome-free electrogalvanized carbon steel finished in a chemical-proof, baked-on coating.
How programmable is the DH412 controller?
The DH412 supports up to 99 steps and 99 patterns with a repetitive operation function. This handles complex multi-stage ramp-and-soak profiles beyond single fixed setpoints.
Is the DH412 backed by manufacturer certifications and warranty?
Yes. Yamato Scientific manufacturing is certified to ISO 9001:2015 and ISO 14001:2015, and LabSupplies.com supplies the DH412 as an authorized dealer with the manufacturer warranty.
