Vacuum Controller For Re-202-A/212-A (Latin America Countries) Overview
The Vacuum Controller For Re-202-A/212-A (Latin America Countries) (DIG-VPCM) regulates absolute vacuum pressure for Yamato Scientific RE202A and RE212A rotary evaporators. Sold by LabSupplies.com, authorized dealer, this unit holds set point across a 1–775 Torr range with ±2 Torr accuracy, giving reproducible distillation and solvent recovery.
Wetted components use 316 stainless steel, PTFE, and chemically resistant rubber, protecting the pressure path against solvent vapor. An integrated SEN-775i-NPT-OEM absolute sensor reads to ±0.1 Torr resolution. Vacuum lines connect through 3/8 inch I.D. hose barbs and a 1/4 inch NPT female port.
Readouts split across a 0.56 inch white LED for live pressure and a 0.36 inch blue LED for set point, switchable between Torr and mbar. USB connectivity enables remote control from a workstation. Mount the controller on a desktop or laboratory pole. Built in the United States, it carries UL, CE, CSA, and RoHS certification.
Key Features
- Absolute pressure control: ±2 Torr (±2.66 mbar) control accuracy referenced to absolute vacuum.
- SEN-775i-NPT-OEM sensor: ±0.1 Torr resolution across a 1–1013 mbar / 1–775 Torr range.
- Dual LED display: 0.56 inch white LED for live pressure, 0.36 inch blue LED for set point, selectable in Torr or mbar.
- USB connectivity: remote control of the controller from a connected workstation.
- Chemically resistant wetted path: 316 stainless steel, PTFE, and chemically resistant rubber.
- Flexible mounting and fittings: desktop or laboratory pole mount with 3/8 inch I.D. hose barbs and 1/4 inch NPT female interface.
How to Choose the Right Rotary Evaporator
Matching a vacuum controller to your rotary evaporator and solvent set determines distillation reproducibility and recovery yield. Weigh these axes before specifying a controller for an RE202A or RE212A workflow.
- Compatibility: confirm the controller is built for your evaporator model and regional configuration, here the RE202A and RE212A Latin America units.
- Control accuracy: tighter set point control, such as ±2 Torr, stabilizes boiling point and limits bumping during sensitive distillations.
- Pressure range: a 1–775 Torr span covers both deep-vacuum and gentle solvent removal without changing instruments.
- Wetted materials: 316 stainless steel, PTFE, and chemically resistant rubber resist aggressive solvent vapors.
- Connectivity and mounting: USB remote control and desktop or pole mounting fit the controller to your bench layout and automation needs.
Specifications
| Specification | Detail |
|---|---|
| Type | Vacuum pressure controller |
| Vacuum Reference | Absolute |
| Sensor | SEN-775i-NPT-OEM |
| Resolution | ±0.1 Torr |
| Pressure Units | Torr, mbar |
| Control Accuracy | ±2 Torr (±2.66 mbar) |
| Pressure Range | 1–1013 mbar / 1–775 Torr |
| Display | 0.56" white LED (pressure), 0.36" blue LED (set point) |
| Connectivity | USB (remote control) |
| Vacuum Interface | 3/8" I.D. hose barbs, 1/4" NPT F |
| Wetted Materials | 316 SS, chemically resistant rubber, PTFE |
| Mounting | Desktop or laboratory pole mount |
| Compliance | UL, CE, CSA and RoHS certified |
| Country of Origin | United States |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| DIG-VPCM | EA | EA |
More in This Series
- Rotary Evaporator (Main Unit) Digital
- Re-202-A Rotary Evaporator, Bm-302-A Water Bath (5L), Glassware A
- Re-202-A Rotary Evaporator, Bm-302-A Water Bath (5L), Glassware B
- Re-202-A Rotary Evaporator, Bm-302-A Water Bath (5L), Glassware C
- Re-202-A Rotary Evaporator, Bo-302-A Oil Bath (5L), Glassware A
- Re-202-A Rotary Evaporator, Bo-302-A Oil Bath (5L), Glassware B
- Re-202-A Rotary Evaporator, Bo-302-A Oil Bath (5L), Glassware C
- Re-212-A Rotary Evaporator, Bm-312-A Water Bath (5L), Glassware A
- Re-212-A Rotary Evaporator, Bm-312-A Water Bath (5L), Glassware B
- Re-212-A Rotary Evaporator, Bm-312-A Water Bath (5L), Glassware C
- Re-212-A Rotary Evaporator, Bm-312-A Oil Bath (5L), Glassware A
- Re-212-A Rotary Evaporator, Bm-312-A Oil Bath (5L), Glassware B
- Re-212-A Rotary Evaporator, Bm-312-A Oil Bath (5L), Glassware C
- Rotary Evaporator (Main Unit) Digital With Vacuum Regulator
- Rev-202M-A Rotary Evaporator With Vacuum Regulator, Bm-302-A Water Bath (5L), Glassware A
- Rev-202M-A Rotary Evaporator With Vacuum Regulator, Bm-302-A Water Bath (5L), Glassware B
- Rev-202M-A Rotary Evaporator With Vacuum Regulator, Bm-302-A Water Bath (5L), Glassware C
- Rev-202M-A Rotary Evaporator With Vacuum Regulator, Bo-302-A Oil Bath (5L), Glassware A
- Rev-202M-A Rotary Evaporator With Vacuum Regulator, Bo-302-A Oil Bath (5L), Glassware B
- Rev-202M-A Rotary Evaporator With Vacuum Regulator, Bo-302-A Oil Bath (5L), Glassware C
- Rev-212M-A Rotary Evaporator With Vacuum Regulator, Bm-312-A Water Bath (5L), Glassware A
- Rev-212M-A Rotary Evaporator With Vacuum Regulator, Bm-312-A Water Bath (5L), Glassware B
- Rev-212M-A Rotary Evaporator With Vacuum Regulator, Bm-312-A Water Bath (5L), Glassware C
- Rev-212M-A Rotary Evaporator With Vacuum Regulator, Bo-312-A Oil Bath (5L), Glassware A
- Rev-212M-A Rotary Evaporator With Vacuum Regulator, Bo-312-A Oil Bath (5L), Glassware B
- Rev-212M-A Rotary Evaporator With Vacuum Regulator, Bo-312-A Oil Bath (5L), Glassware C
- Glassware Set A (Standard Diagonal) For Re-202-A/212-A And Rev-202M-A/212M-A
- Glassware Set B (Vertical High Boiling Point) For Re-202-A/212-A And Rev-202M-A/212M-A
- Glassware Set C (Cold Finger Vertical) For Re-202-A/212-A And Rev-202M-A/212M-A
- Vacuum Regulator For Re-202-A/212-A
Why Buy From LabSupplies.com
LabSupplies.com supplies the DIG-VPCM vacuum controller as a genuine Yamato Scientific component, backed by the support procurement teams need to specify with confidence.
- Authorized Yamato Scientific dealer: genuine unit with full manufacturer warranty.
- In stock: ready to ship from USA inventory.
- Lab-equipment specialists: dedicated team for spec and compatibility questions.
Frequently Asked Questions
Which rotary evaporators is this vacuum controller designed for?
It is designed for Yamato Scientific RE202A and RE212A rotary evaporators in the Latin America country configuration. Confirm your model before ordering.
What pressure range and accuracy does the DIG-VPCM provide?
It controls from 1 to 775 Torr (1–1013 mbar) with ±2 Torr (±2.66 mbar) accuracy and ±0.1 Torr resolution, referenced to absolute vacuum.
Which pressure units does the display show?
Both Torr and mbar. A 0.56 inch white LED shows live pressure and a 0.36 inch blue LED shows the set point.
What materials contact the vacuum path?
316 stainless steel, PTFE, and chemically resistant rubber make up the wetted components, resisting solvent vapor exposure.
How does the controller connect to a vacuum line?
Through 3/8 inch I.D. hose barbs and a 1/4 inch NPT female fitting. It mounts on a desktop or laboratory pole.
Can the controller be operated remotely?
Yes. A USB interface enables remote control from a connected workstation.
