Remote Dispense Configuration - With Uv Oxidation Lamp, /60Hz Overview
The Remote Dispense Configuration - With Uv Oxidation Lamp, /60Hz (model WC301UVR) is a Type I ultrapure Water Purification System from Yamato Scientific, supplied by LabSupplies.com as an authorized dealer. Producing 18.2 MΩ·cm resistivity water with TOC below 5 ppb, this compact unit serves organic and analytical chemistry workflows.
Purification pairs conditioning and polishing cartridges with a 185/254 nm UV oxidation lamp that sterilizes bacteria and reduces total organic carbon. A 0.2 micron final filter polishes output to under 1 cfu/ml. Quick-change, no-tools cartridges use premium ResinTech ion-exchange media for fast media swaps.
Operating on 120V / 60 Hz, the system measures 21.6 × 14.7 × 14.4 inches and weighs 49.5 lbs. Real-time quality monitoring with leak detection runs continuously. Made in the USA, it dispenses ultrapure water remotely at a typical 2.5 LPM (0.67 GPM).
Key Features
- Type I ultrapure output: 18.2 MΩ·cm resistivity, TOC below 5 ppb, and bacteria under 1 cfu/ml for analytical and organic chemistry.
- UV oxidation lamp: dual-wavelength 185/254 nm UV sterilizes bacteria and reduces total organic carbon.
- 0.2 micron final filter: polishes dispensed water at the point of use.
- Remote dispense configuration: delivers a typical 2.5 LPM (0.67 GPM) flow rate.
- Quick-change cartridges: no-tools design with premium ResinTech ion-exchange media.
- Real-time monitoring: continuous water-quality readout with integrated leak detection.
How to Choose the Right Water Purification System
Match the system to the water grade your assays demand, the way you draw water, and the feed supply available at the bench. Use the criteria below to confirm fit .
- Water quality grade: Type I ultrapure (18.2 MΩ·cm, TOC under 5 ppb) suits HPLC, ICP, and trace analysis; lower grades cannot meet these tolerances.
- Dispense configuration: a remote dispense head lets you place the draw point where the work happens, away from the cabinet.
- TOC control: the 185/254 nm UV oxidation stage reduces organic carbon and sterilizes bacteria for sensitive organic chemistry.
- Flow rate: a 2.5 LPM (0.67 GPM) typical output supports routine fill and rinse tasks without long waits.
- Feed water requirement: verify your supply is below 20 µS/cm to keep cartridge life and output stable.
- Footprint and power: confirm the 21.6 × 14.7 × 14.4 inch envelope and 120V / 60 Hz circuit fit the bench and outlet.
Specifications
| Specification | Detail |
|---|---|
| Voltage | 115V |
| Type | Type I ultrapure water purification system |
| Purification Process | Conditioning and polishing cartridges plus UV oxidation (185/254 nm) for bacteria sterilization and TOC reduction, with a 0.2 µm final filter |
| TOC | < 5 ppb |
| TOC Monitor | Not included |
| Dispense Configuration | Remote dispense |
| Power | 120V / 60 Hz |
| Application | Organic and analytical chemistry — ultrapure, analytical, low TOC |
| Water Quality | Type I ultrapure — 18.2 MΩ·cm resistivity |
| Bacteria | < 1 cfu/ml |
| Flow Rate | 2.5 LPM / 0.67 GPM (typical) |
| Feed Water Requirement | < 20 µS/cm |
| Final Filter | 0.2 micron |
| Monitoring | Real-time quality monitoring with leak detection |
| Cartridges | Quick-change, no-tools design; premium ResinTech ion-exchange media |
| Dimensions (H × W × D) | 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) in |
| Country of Origin | United States |
| GTIN (Barcode) | 797059929344 |
| Shipping Weight | 49.5 lbs |
| Dimensions (L × W × H) | 26.5 × 26.63 × 20.3 in |
| ISO 9001:2015 | Contact Customer Service |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| WC-301UVR | EA | EA |
Documentation
More in This Series
- Distilled / Deionized Water Purification System ~1.8L/Hr. 20L Tank With External Transformer
- Distilled / Deionized Water Purification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Waterpurification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank Single Phase With External Transformer
- Deionized Water Purification System 0.5~1.0L/Min 115
- Benchtop Or Wall Mount Base System, /60Hz
- Benchtop Or Wall Mount Base System, /50Hz
- Remote Dispense Configuration Base System, /60Hz
- Remote Dispense Configuration Base System, /50Hz
- Benchtop - With Uv Oxidation Lamp Installed, /60Hz
- Benchtop - With Uv Oxidation Lamp Installed, /50Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /50Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Benchtop - With Ultrafiltration Module, /60Hz
- Benchtop - With Ultrafiltration Module, /50Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /60Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /50Hz
- Benchtop - With Uv And Uf Installed, /60Hz
- Benchtop - With Uv And Uf Installed, /50Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /60Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /50Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /60Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /50Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /60Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /50Hz
- Direct Feed Option (Factory Installed)
- Wall Mount Bracket
- Dispensing Gun Option (Factory Installed)
- High Purity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
- High Purity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
Why Buy From LabSupplies.com
Order the Yamato Scientific WC301UVR direct from LabSupplies.com and receive a genuine factory unit backed by manufacturer support. Our lab-equipment specialists answer spec questions before you purchase.
- Authorized Yamato Scientific dealer — genuine unit with manufacturer warranty.
- In stock and ready to ship.
- Ships from USA inventory.
- Dedicated lab-equipment specialists for technical and configuration questions.
Frequently Asked Questions
What water quality does the WC301UVR produce?
The WC301UVR produces Type I ultrapure water at 18.2 MΩ·cm resistivity, with TOC below 5 ppb and bacteria under 1 cfu/ml. A 185/254 nm UV oxidation lamp and 0.2 micron final filter handle organic reduction and sterilization.
What voltage and power does this system require?
The system runs on 120V / 60 Hz (115V). Confirm a matching standard outlet is available at the install location before purchase.
What are the dimensions and weight of the unit?
The cabinet measures 21.6 × 14.7 × 14.4 inches (54.8 × 37 × 36.5 cm) and weighs 49.5 lbs. Verify the footprint fits your bench and the remote dispense head can reach the work point.
Is a TOC monitor included with the WC301UVR?
No, a TOC monitor is not included with this configuration. The system reduces TOC to below 5 ppb through UV oxidation and provides real-time water-quality monitoring with leak detection.
What feed water does the system require?
Feed water must be below 20 µS/cm conductivity. Staying within this requirement protects cartridge life and maintains stable ultrapure output at the typical 2.5 LPM (0.67 GPM) flow rate.
Where is the WC301UVR manufactured?
The WC301UVR is made in the USA by Yamato Scientific. LabSupplies.com ships it from USA inventory as an authorized dealer.
