Remote Dispense Configuration - With Ultrafiltration Module, /60Hz Overview
The Remote Dispense Configuration - With Ultrafiltration Module, /60Hz (Yamato WB301UFR) is a Type I water purification system that delivers 18.2 MΩ·cm ultrapure water at the point of use. Sold by LabSupplies.com, authorized dealer for Yamato Scientific, this compact unit pairs conditioning and polishing cartridges with an integrated ultrafiltration module.
Ultrafiltration plus a 0.2 micron final filter removes pyrogens and produces nuclease-free water for sensitive protocols. Quick-change, no-tools cartridges use premium ResinTech ion-exchange media, simplifying maintenance. Real-time quality monitoring with leak detection tracks output continuously, holding TOC below 15 ppb and bacteria under 1 cfu/ml.
Operating on 120V / 60 Hz, the WB301UFR draws standard 115V power and occupies a 21.6" × 14.7" × 14.4" footprint at 48.2 lbs. Typical flow reaches 2.5 LPM (0.67 GPM) from feed water below 20 µS/cm. Made in USA, the remote dispense head separates the purifier from the draw point.
Key Features
- Type I ultrapure output: 18.2 MΩ·cm resistivity with TOC < 15 ppb and bacteria < 1 cfu/ml.
- Integrated ultrafiltration: removes pyrogens and delivers nuclease-free water behind a 0.2 micron final filter.
- Quick-change cartridges: no-tools design using premium ResinTech ion-exchange media.
- Real-time monitoring: continuous quality readout with built-in leak detection.
- Remote dispense head: separates the purifier from the point of use for flexible bench layout.
- Typical flow rate: 2.5 LPM (0.67 GPM) from feed water under 20 µS/cm.
How to Choose the Right Water Purification System
Selecting a lab water system starts with the purity grade your protocols demand and the way you draw water at the bench. Match these axes to your workflow before purchasing.
- Water quality grade: Type I (18.2 MΩ·cm) suits HPLC, molecular biology, and trace analysis; lower grades cannot support nuclease-free work.
- Ultrafiltration: required when protocols need pyrogen-free and nuclease-free water, as this configuration provides.
- Feed water quality: confirm your supply meets the < 20 µS/cm input requirement for stable performance.
- Flow rate: a typical 2.5 LPM (0.67 GPM) draw matches routine bench dispensing demands.
- Dispense configuration: remote dispense decouples the purifier from the draw point, freeing bench space.
- Voltage and footprint: verify 115V supply and a 21.6" × 14.7" × 14.4" clearance at the install location.
Specifications
| Specification | Detail |
|---|---|
| Voltage | 115V |
| Type | Type I ultrapure water purification system |
| Purification Process | Conditioning and polishing cartridges plus ultrafiltration for pyrogen removal and nuclease-free water, with a 0.2 µm final filter |
| TOC | < 15 ppb |
| TOC Monitor | Not included |
| Dispense Configuration | Remote dispense |
| Power | 120V / 60 Hz |
| Application | Type I water requiring pyrogen-free / nuclease-free quality |
| Water Quality | Type I ultrapure — 18.2 MΩ·cm resistivity |
| Bacteria | < 1 cfu/ml |
| Flow Rate | 2.5 LPM / 0.67 GPM (typical) |
| Feed Water Requirement | < 20 µS/cm |
| Final Filter | 0.2 micron |
| Monitoring | Real-time quality monitoring with leak detection |
| Cartridges | Quick-change, no-tools design; premium ResinTech ion-exchange media |
| Dimensions (H × W × D) | 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) in |
| Country of Origin | United States |
| GTIN (Barcode) | 797059929405 |
| Shipping Weight | 48.2 lbs |
| Dimensions (L × W × H) | 26.5 × 26.63 × 20.3 in |
| ISO 9001:2015 | Contact Customer Service |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| WB-301UFR | EA | EA |
Documentation
More in This Series
- Distilled / Deionized Water Purification System ~1.8L/Hr. 20L Tank With External Transformer
- Distilled / Deionized Water Purification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Waterpurification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank Single Phase With External Transformer
- Deionized Water Purification System 0.5~1.0L/Min 115
- Benchtop Or Wall Mount Base System, /60Hz
- Benchtop Or Wall Mount Base System, /50Hz
- Remote Dispense Configuration Base System, /60Hz
- Remote Dispense Configuration Base System, /50Hz
- Benchtop - With Uv Oxidation Lamp Installed, /60Hz
- Benchtop - With Uv Oxidation Lamp Installed, /50Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /60Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /50Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Benchtop - With Ultrafiltration Module, /60Hz
- Benchtop - With Ultrafiltration Module, /50Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /50Hz
- Benchtop - With Uv And Uf Installed, /60Hz
- Benchtop - With Uv And Uf Installed, /50Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /60Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /50Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /60Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /50Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /60Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /50Hz
- Direct Feed Option (Factory Installed)
- Wall Mount Bracket
- Dispensing Gun Option (Factory Installed)
- High Purity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
- High Purity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so every WB301UFR ships as a genuine unit backed by the manufacturer warranty. Our lab-equipment specialists answer specification questions before you order.
- Authorized dealer: genuine Yamato Scientific unit with full manufacturer warranty.
- In stock: ready to ship from USA inventory.
- Made in USA: manufactured in the United States.
- Specialist support: dedicated lab-equipment specialists help confirm fit and specs.
Frequently Asked Questions
What water quality does the WB301UFR produce?
The WB301UFR produces Type I ultrapure water at 18.2 MΩ·cm resistivity. TOC stays below 15 ppb and bacteria below 1 cfu/ml, with ultrafiltration delivering pyrogen-free, nuclease-free water through a 0.2 micron final filter.
What voltage and power does this system require?
It operates on 120V / 60 Hz, drawing standard 115V power. Confirm a matching outlet at the install location before ordering.
What are the dimensions and weight of the unit?
The purifier measures 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) and weighs 48.2 lbs. Plan bench clearance accordingly; the remote dispense head can be positioned away from the unit.
What flow rate and feed water does the WB301UFR need?
Typical output is 2.5 LPM (0.67 GPM). Feed water must measure below 20 µS/cm for stable performance.
How is cartridge maintenance handled?
Cartridges use a quick-change, no-tools design with premium ResinTech ion-exchange media. Real-time quality monitoring with leak detection tracks performance so you know when service is due.
Is a TOC monitor included with this configuration?
No, a TOC monitor is not included with the WB301UFR. The system holds TOC below 15 ppb and provides real-time quality monitoring with leak detection.
