Benchtop - With Uv And Uf Installed, /50Hz Overview
The Benchtop - With Uv And Uf Installed, /50Hz (model WG311UVUFB) from Yamato Scientific is a Type I ultrapure water purification system delivering 18.2 MΩ·cm resistivity. LabSupplies.com, an authorized dealer, supplies this unit for genetics testing and biological work that demands consistent low-TOC ultrapure water.
Purification combines conditioning and polishing cartridges with UV oxidation and ultrafiltration, achieving bacteria sterilization, TOC reduction, and pyrogen removal. A 0.2 micron final filter polishes the dispensed output. Quick-change, no-tools cartridges carry premium ResinTech ion-exchange media. Real-time quality monitoring with leak detection tracks system performance continuously.
Operating on 220V / 50 Hz power, the system mounts on a bench or wall to suit tight lab footprints, measuring 21.6" × 14.7" × 14.4". Manufactured in the USA, the unit weighs 37.4 lbs. TOC runs below 5 ppb while bacteria stays under 1 cfu/ml.
Key Features
- UV oxidation and ultrafiltration: delivers bacteria sterilization, TOC reduction, and pyrogen removal in one polishing stage.
- Type I ultrapure output: 18.2 MΩ·cm resistivity, TOC below 5 ppb, and bacteria under 1 cfu/ml.
- 2.5 LPM flow rate: typical 0.67 GPM dispense supports routine ultrapure draws.
- Quick-change cartridges: no-tools design with premium ResinTech ion-exchange media.
- Real-time monitoring: continuous water-quality readout plus integrated leak detection.
- Flexible mounting: benchtop or wall-mount installation with a 0.2 micron final filter.
How to Choose the Right Water Purification System
Matching a purification system to your workflow starts with the water grade your assays require, then the technologies and site conditions that sustain it. Use these axes to scope the right unit.
- Water quality grade: Type I ultrapure at 18.2 MΩ·cm suits genetics, molecular, and biological work; lower grades will not meet those tolerances.
- Purification technology: UV oxidation and ultrafiltration target TOC, bacteria, and pyrogens — confirm your application needs that level of polishing.
- Flow rate: a 2.5 LPM dispense should match the volume and pace of daily draws at the bench.
- Voltage and power: verify your site supplies 220V / 50 Hz before specifying this configuration.
- Footprint and mounting: benchtop or wall-mount flexibility helps fit constrained lab space at 21.6" × 14.7" × 14.4".
- Feed water requirement: incoming supply must be under 20 µS/cm for the system to perform as rated.
Specifications
| Specification | Detail |
|---|---|
| Voltage | 220V |
| Type | Type I ultrapure water purification system |
| Purification Process | Conditioning and polishing cartridges plus UV oxidation and ultrafiltration (bacteria sterilization, TOC reduction, pyrogen removal), with a 0.2 µm final filter |
| TOC | < 5 ppb |
| TOC Monitor | Not included |
| Dispense Configuration | Benchtop or wall-mount |
| Power | 220V / 50 Hz |
| Application | Genetics testing and biological work — ultrapure, biological, low TOC |
| Water Quality | Type I ultrapure — 18.2 MΩ·cm resistivity |
| Bacteria | < 1 cfu/ml |
| Flow Rate | 2.5 LPM / 0.67 GPM (typical) |
| Feed Water Requirement | < 20 µS/cm |
| Final Filter | 0.2 micron |
| Monitoring | Real-time quality monitoring with leak detection |
| Cartridges | Quick-change, no-tools design; premium ResinTech ion-exchange media |
| Dimensions (H × W × D) | 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) in |
| Country of Origin | United States |
| GTIN (Barcode) | 797059929436 |
| Shipping Weight | 37.4 lbs |
| Dimensions (L × W × H) | 26.5 × 18.63 × 20.3 in |
| ISO 9001:2015 | Contact Customer Service |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| WG-311UVUFB | EA | EA |
Documentation
More in This Series
- Distilled / Deionized Water Purification System ~1.8L/Hr. 20L Tank With External Transformer
- Distilled / Deionized Water Purification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Waterpurification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank Single Phase With External Transformer
- Deionized Water Purification System 0.5~1.0L/Min 115
- Benchtop Or Wall Mount Base System, /60Hz
- Benchtop Or Wall Mount Base System, /50Hz
- Remote Dispense Configuration Base System, /60Hz
- Remote Dispense Configuration Base System, /50Hz
- Benchtop - With Uv Oxidation Lamp Installed, /60Hz
- Benchtop - With Uv Oxidation Lamp Installed, /50Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /60Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /50Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Benchtop - With Ultrafiltration Module, /60Hz
- Benchtop - With Ultrafiltration Module, /50Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /60Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /50Hz
- Benchtop - With Uv And Uf Installed, /60Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /60Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /50Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /60Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /50Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /60Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /50Hz
- Direct Feed Option (Factory Installed)
- Wall Mount Bracket
- Dispensing Gun Option (Factory Installed)
- High Purity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
- High Purity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
Why Buy From LabSupplies.com
LabSupplies.com sources the WG311UVUFB through authorized Yamato Scientific channels, so you receive a genuine unit backed by the manufacturer warranty. Our lab-equipment specialists answer spec questions before you commit to a purchase.
- Authorized Yamato Scientific dealer: genuine equipment with full manufacturer warranty.
- In stock: ready to ship from USA inventory.
- Specialist support: dedicated lab-equipment team for configuration and spec questions.
Frequently Asked Questions
What water quality does the WG311UVUFB produce?
It produces Type I ultrapure water at 18.2 MΩ·cm resistivity. TOC stays below 5 ppb and bacteria below 1 cfu/ml, supporting genetics testing and biological applications.
What voltage and power does this system require?
The WG311UVUFB operates on 220V / 50 Hz power. Confirm your facility supplies this configuration before installation.
Is a TOC monitor included with this unit?
No, a TOC monitor is not included with this configuration. The system does provide real-time water-quality monitoring with leak detection.
What are the system dimensions and mounting options?
The unit measures 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) and installs either on a benchtop or wall-mounted. It weighs 37.4 lbs.
What feed water quality is required?
Feed water must be under 20 µS/cm. Meeting this requirement allows the system to perform at its rated ultrapure output.
How does the system handle bacteria and pyrogens?
UV oxidation and ultrafiltration provide bacteria sterilization, TOC reduction, and pyrogen removal. A 0.2 micron final filter polishes the dispensed water before use.
