Natural Convection Oven Programmable 162L Overview
The Natural Convection Oven Programmable 162L (model DVS603C) from Yamato Scientific is a 162 L natural convection oven built for repeatable drying, baking, and heat-treatment work. Programmable control lets technicians automate multi-step temperature and time profiles. LabSupplies.com supplies this unit as an authorized Yamato Scientific dealer.
Natural convection moves heated air by gravity rather than a forced fan, reducing airflow disturbance for lightweight samples and powders. Gentle, fan-free circulation suits work where particle scatter or sample displacement is a concern. Chamber capacity measures 162 L, giving room for batch loads and larger labware.
Two voltage builds cover different lab power standards: the DVS603C runs on 115V and the DVS613C runs on 220V. Both share identical 162 L capacity and programmable operation. Confirm your facility's circuit before ordering. LabSupplies.com ships genuine Yamato units from USA inventory.
Key Features
- Natural convection heating: fan-free gravity airflow minimizes sample disturbance and particle scatter.
- Programmable control: automate multi-step temperature and time profiles for repeatable runs.
- 162 L chamber: accommodates batch drying and larger labware loads.
- DVS603C: 115V configuration for North American lab circuits.
- DVS613C: 220V configuration for international and high-voltage installations.
How to Choose the Right Convection Oven
Selecting a convection oven means matching chamber size, control sophistication, and power to your throughput. Weigh these factors :
- Capacity: chamber volume determines how many samples or how much labware fits per run; the 162 L size targets mid-to-high batch loads.
- Control type: programmable controllers automate temperature ramps and dwell times, while analog units require manual setting, so programmable models suit validated, repeatable protocols.
- Temperature range: confirm the oven reaches the temperatures your drying or heat-treatment method demands.
- Voltage: match the unit to your available circuit, 115V (DVS603C) or 220V (DVS613C), to avoid rewiring.
- Convection method: natural convection protects lightweight samples, whereas forced-air models speed drying of dense loads.
- Footprint: verify bench or floor clearance against the unit's external dimensions before installation.
Specifications
| Specification | Detail |
|---|---|
| Capacity | 162 L |
| Voltage | 115V |
| Circulation Method | Natural convection |
| Temperature Accuracy | ±1.0°C (at 260°C) *2 |
| Temperature Distribution | ±5.0°C (at 260°C) *2 |
| Max. Temperature Reaching Time | Approx. 90 min |
| Temperature Control System | 6-pattern program PID control by microprocessor |
| Sensor | K-thermocouple |
| Interior Material | Stainless steel |
| Exterior Material | Cold-rolled steel plate with melamine resin baked finish |
| Heat Insulation | Glass wool |
| Observation Window | 250 × 280 mm chemically strengthened glass (3 panes) |
| Safety Devices | Self-diagnostic functions (sensor error, heater disconnection, SSR short-circuit, automatic overheat prevention); overheat prevention; overcurrent leakage breaker |
| Heater | Stainless pipe heater, 1.36 kW |
| Operating Temperature Range | ambient +5 to 260°C *1 |
| Material | Steel plate SPCC powder coating (exterior) Stainless steel (interior) |
| Country of Origin | China |
| GTIN (Barcode) | 797059926312 |
| Shipping Weight | 235 lbs |
| Dimensions (L × W × H) | 36 × 36 × 45 in |
| Component Size | 162 L |
*1 No-load operation of bath only; maximum temperature varies with circumstances and operating conditions. *2 Measured under ambient temperature 23°C ±5°C, humidity 65%RH ±20%, per Yamato Scientific test conditions.
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| DVS-603C | 115V | EA |
| DVS-613C | 220V | EA |
Documentation
- Product Brochure
- ISO 9001
- ISO 14001
- ISO 45001
- CE Certification
- Yamato Scientific Official Product Page
More in This Series
- Natural Convection Oven 28L
- Natural Convection Oven 74L
- Natural Convection Oven 153L
- Natural Convection Oven Programmable 99L
- High Temperature Natural Convection Oven Programmable 13.75L
- Natural Convection Glassware Drying Oven 92L
- Natural Convection Glassware Drying Oven With Sterilization Lamp 92L
- Natural Convection Glassware Drying Oven 445L
- Natural/Forced Convection Glassware Drying Oven With Sterilization Lamp 445L
- Forced Convection Oven 27L
- Forced Convection Oven 90L
- Forced Convection Oven 150L
- Forced Convection Oven Programmable 27L
- Forced Convection Oven Programmable 90L
- Forced Convection Oven Programmable 150L
- Forced Convection Oven Programmable 300L
- Forced Convection Oven Programmable 535L
- Forced Convection Oven Programmable Energy Saving 90L
- Forced Convection Oven Programmable Energy Saving 150L
- Forced Convection Oven Programmable Energy Saving 300L
- Forced Convection Oven Programmable Energy Saving 540L
- Forced / Natural Convection Oven Programmable Energy Saving 27L With External Transformer
- Forced / Natural Convection Oven Programmable Energy Saving 90L
- Forced / Natural Convection Oven Programmable Energy Saving 150L
- Forced Convection Oven Programmable Energy Saving 300L
- Forced Convection Oven Programmable Energy Saving 540L
Why Buy From LabSupplies.com
Order the DVS603C or DVS613C directly from LabSupplies.com and receive a genuine Yamato Scientific unit backed by the manufacturer warranty.
- Authorized Yamato Scientific dealer: every unit is genuine and covered by the manufacturer warranty.
- In stock: ready to ship from USA inventory.
- Lab-equipment specialists: dedicated support for spec and configuration questions.
- Direct online ordering: complete your purchase without sales back-and-forth.
Frequently Asked Questions
What is the temperature range of the DVS603C convection oven?
Contact for specification. The exact maximum temperature is not listed in current source data; our lab-equipment specialists can confirm the verified range before you order.
What is the chamber capacity and footprint?
Both the DVS603C and DVS613C offer a 162 L chamber. Exact internal and external dimensions are available on request from our specialists.
What voltage do these ovens require?
The DVS603C runs on 115V and the DVS613C runs on 220V. Choose the model that matches your facility's circuit before installation.
What materials are used in the chamber construction?
Contact for specification. Chamber and exterior material details are not in current source data; our specialists can confirm them prior to purchase.
What is the difference between the DVS603C and DVS613C?
Voltage is the only difference. The DVS603C is the 115V build and the DVS613C is the 220V build; both share the same 162 L capacity and programmable control.
Is this oven natural convection with programmable control?
Yes. The unit uses fan-free natural convection and offers programmable control to automate multi-step temperature profiles for hands-off, repeatable runs.
