Muffle Furnace With Communication Port 30L Overview
The Muffle Furnace With Communication Port 30L (Yamato Scientific FO811CR) is a 30 L high-temperature furnace built for ashing, ignition, and heat-treatment workflows. LabSupplies.com supplies this unit as an authorized dealer of Yamato Scientific, delivering a genuine instrument with full manufacturer support.
An integrated communication port lets the FO811CR connect to external data systems for monitoring and logging, supporting documented, repeatable thermal protocols. The 30 L chamber accommodates crucibles, sample trays, and multi-sample batches in a single run.
The FO811CR operates on a 220V supply, so confirm your bench or facility circuit before installation. Additional specifications including temperature range, chamber dimensions, weight, and certifications are available upon request.
Key Features
- 30 L chamber: sized for crucibles, trays, and multi-sample ashing or ignition batches.
- Communication port: connects to external systems for monitoring and data logging of thermal runs.
- Muffle furnace design: isolates samples from combustion products for clean, high-temperature processing.
- 220V operation: engineered for a dedicated 220V laboratory supply.
- Yamato Scientific build: genuine instrument supplied through an authorized dealer.
How to Choose the Right Muffle Furnace
Selecting a muffle furnace comes down to matching chamber size, control capability, and power to your specific thermal workload. Weigh these axes before you commit to a model.
- Capacity: chamber volume determines how many crucibles or samples you can process per run; the FO811CR offers 30 L.
- Temperature range: confirm the rated maximum matches your ashing, ignition, or heat-treat protocol before purchase.
- Control and connectivity: a communication port enables external monitoring and data logging for documented, repeatable cycles.
- Voltage: verify facility power; this unit requires a 220V supply.
- Footprint: match chamber size and external dimensions to available bench or floor space.
- Safety: review interlocks and over-temperature protection for your lab's operating standards.
Specifications
| Specification | Detail |
|---|---|
| Capacity | 30 L |
| Voltage | 220V |
| Operating Temperature Range | 100 to 1150°C *1 |
| Temperature Accuracy | ±2°C (at 1150°C) *2 |
| Temperature Control System | PID control (VS6 controller) |
| Sensor | R-thermocouple |
| Interior Material | Ceramic fiber |
| Exterior Material | Steel with melamine/epoxy composite resin coating; SUS304 |
| Operation Function | Fixed temperature, timer (auto start/stop), program (up to 6 patterns) |
| Safety Devices | Self-diagnostic (memory error, sensor error); earth-leakage/circuit breaker; overheat prevention device |
| Heater | Iron-chrome wire, 4.0 kW |
| Internal Dimensions | 300 × 400 × 250 mm |
| Material | Steel, Melamine, Epoxy composite resin coating, Stainless steel, SUS304 (body) Ceramic fiber (furnace and door) |
| Country of Origin | China |
| GTIN (Barcode) | 797059927050 |
| Shipping Weight | 234 lbs |
| Dimensions (L × W × H) | 36 × 36 × 38 in |
| Component Size | 30 L |
*1 No-load operation of bath only; maximum temperature varies with circumstances and operating conditions. *2 Measured under ambient temperature 23°C ±5°C, humidity 65%RH ±20%, per Yamato Scientific test conditions.
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| FO-811CR | EA | EA |
Documentation
