Muffle Furnace With Communication Port 17.5L Overview
The Yamato Scientific Muffle Furnace With Communication Port (model FO611CR) is a 17.5 L high-temperature furnace built for ashing, ignition, and heat-treatment work. LabSupplies.com, an authorized dealer, supplies this unit for laboratories that need a sizable chamber paired with data-capable temperature control.
An integrated communication port lets the furnace connect to external monitoring or logging systems, supporting documented thermal cycles and traceable records. The 17.5 L chamber accommodates crucibles, sample boats, and larger batch loads in a single run.
Operating on a 220V supply, the FO611CR suits facilities with dedicated higher-voltage service. Confirm circuit and outlet requirements against your installation site before ordering. Additional dimensions, weight, country of origin, and certification details are available on request.
Key Features
- 17.5 L chamber: roomy capacity for crucibles, sample boats, and multi-sample batch processing.
- Communication port: connects to external monitoring or data-logging systems for traceable thermal records.
- 220V operation: engineered for facilities with dedicated higher-voltage service.
- Yamato Scientific build: genuine manufacturer unit supplied through an authorized dealer.
- Single-model configuration: the FO611CR ships as one defined specification, simplifying procurement.
How to Choose the Right Muffle Furnace
Selecting a muffle furnace comes down to matching chamber size, temperature capability, and control features to your throughput and documentation needs. Review these axes before you specify a unit.
- Capacity: chamber volume sets how many crucibles or sample boats you can run per cycle; the FO611CR offers 17.5 L for larger batches.
- Temperature range: confirm the maximum operating temperature meets your ashing or ignition protocol; request the rated range for this model.
- Control and data capability: a communication port enables external logging and traceable cycles for regulated or audited workflows.
- Voltage and site power: verify your facility supplies 220V service and the correct circuit before installation.
- Footprint and weight: check bench or floor space and load-bearing capacity against the unit's dimensions.
- Safety features: evaluate over-temperature protection and interlocks for the materials you process.
Specifications
| Specification | Detail |
|---|---|
| Capacity | 17.5 L |
| Voltage | 220V |
| Operating Temperature Range | 100 to 1150°C *1 |
| Temperature Accuracy | ±2°C (at 1150°C) *2 |
| Temperature Control System | PID control (VS6 controller) |
| Sensor | R-thermocouple |
| Interior Material | Ceramic fiber |
| Exterior Material | Steel with melamine/epoxy composite resin coating; SUS304 |
| Operation Function | Fixed temperature, timer (auto start/stop), program (up to 6 patterns) |
| Safety Devices | Self-diagnostic (memory error, sensor error); earth-leakage/circuit breaker; overheat prevention device |
| Heater | Iron-chrome wire, 3.0 kW |
| Internal Dimensions | 250 × 350 × 200 mm |
| Material | Steel, Melamine, Epoxy composite resin coating, Stainless steel, SUS304 (body) Ceramic fiber (furnace and door) |
| Country of Origin | China |
| GTIN (Barcode) | 797059927036 |
| Shipping Weight | 202 lbs |
| Dimensions (L × W × H) | 36 × 36 × 37 in |
| Component Size | 17 L |
*1 No-load operation of bath only; maximum temperature varies with circumstances and operating conditions. *2 Measured under ambient temperature 23°C ±5°C, humidity 65%RH ±20%, per Yamato Scientific test conditions.
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| FO-611CR | EA | EA |
Documentation
More in This Series
- Muffle Furnace With Communication Port 1.5L
- Muffle Furnace With Communication Port 3.75L
- Muffle Furnace With Communication Port 7.5L
- Muffle Furnace With Communication Port 9L
- Muffle Furnace With Communication Port 11.3L
- Muffle Furnace With Communication Port 23.6L
- Muffle Furnace With Communication Port 30L
- High Performance Muffle Furnace 1.5L
- High Performance Muffle Furnace 7.5L
- High Performance Muffle Furnace 11.3L
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so the FO611CR ships as a genuine factory unit backed by the manufacturer warranty. Order directly and our lab-equipment specialists are ready to answer spec questions before you commit.
- Authorized Yamato dealer: genuine unit with full manufacturer warranty.
- In stock: ready to process and ship from USA inventory.
- Specialist support: dedicated lab-equipment team for technical and spec questions.
- Direct purchase: straightforward ordering, no gatekeeping.
Frequently Asked Questions
What is the chamber capacity of the Yamato FO611CR muffle furnace?
The FO611CR has a 17.5 L chamber, sized for crucibles, sample boats, and larger batch loads in a single cycle.
What voltage does the FO611CR require?
The FO611CR operates on a 220V supply. Confirm your facility provides dedicated higher-voltage service and the correct circuit before installation.
What is the maximum operating temperature of this furnace?
Contact for specification. The rated temperature range for the FO611CR is available on request from our lab-equipment specialists.
What does the communication port do?
The communication port connects the furnace to external monitoring or data-logging systems, supporting documented thermal cycles and traceable temperature records.
Is this a genuine Yamato Scientific unit with a warranty?
Yes. LabSupplies.com is an authorized Yamato Scientific dealer, so the FO611CR ships as a genuine factory unit backed by the manufacturer warranty.
What are the dimensions and weight of the FO611CR?
Contact for specification. Full dimensions, weight, and footprint details are available on request to confirm bench or floor placement.
