Clean Oven 91L 3 Phase Overview
The Clean Oven 91L 3 Phase (DT411) is a forced-convection Class 100 clean oven from Yamato Scientific, supplied through LabSupplies.com as an authorized dealer. Built for temperature testing in dust-free environments, this unit holds a 91 L chamber and reaches a maximum of 360°C across an operating range of ambient +30 to 360°C.
Chamber construction pairs a stainless steel interior with an exterior of chrome-free electrogalvanized carbon steel finished in a chemical-proof, baked-on coating. A V type controller shows power consumption, CO2 emissions, and heater manipulated variables directly on the panel. Three-color indication signals HEPA filter replacement timing, while anti-fouling casters prevent wheel contamination during transport.
Power draws from a 220V 3-phase supply, and a phase-reversal relay detects an incorrect power source at installation. Footprint measures 52 × 35 × 76 inches at roughly 800 lbs. Manufactured in Japan, the oven carries ISO 9001:2015 and ISO 14001:2015 certification documentation.
Key Features
- Class 100 forced convection: maintains a dust-free chamber for clean temperature testing.
- V type controller: displays power consumption, CO2 emissions, and heater manipulated variables on the panel for improved visibility and operability.
- Three-color HEPA indication: signals filter replacement timing at a glance.
- Phase-reversal relay: detects incorrect power source wiring during installation for added safety.
- Anti-fouling casters: prevent wheel contamination while moving the unit.
- φ33mm cable port: larger access for routing instrumentation and sensors.
How to Choose the Right Clean Oven
Matching a clean oven to your workflow comes down to chamber size, thermal range, and the cleanliness class your process requires. Use these axes to confirm the DT411 fits your application before purchase.
- Capacity: the 91 L chamber sets how many samples or fixtures you can process per cycle, so size it to your batch load.
- Temperature range: an ambient +30 to 360°C span covers most curing, drying, and burn-in protocols; verify your target set point sits inside it.
- Cleanliness class: Class 100 forced convection suits dust-sensitive testing where particulate contamination would compromise results.
- Voltage and power: this model requires a 220V 3-phase circuit, so confirm your site service before installation.
- Footprint and mobility: at 52 × 35 × 76 inches and about 800 lbs, plan floor space and use the anti-fouling casters for positioning.
- Monitoring and safety: the V type controller and phase-reversal relay matter where energy reporting and installation safeguards are priorities.
Specifications
| Specification | Detail |
|---|---|
| Capacity | 91 L |
| Max Temperature | 360°C |
| Voltage | 220V |
| Power | 3 Phase |
| Circulation Method | Forced convection |
| Temperature Accuracy | ±0.3°C (at 360°C) *2 |
| Temperature Fluctuation | ±0.5°C (at 360°C) |
| Temperature Distribution | ±4.0°C (at 360°C) *2 |
| Clean Level | Class 100 (at stable temperature) |
| Filter | Heat-resistant HEPA filter (>99.97% at 0.3 µm) |
| Temperature Control System | PID-V control |
| Heater | Stainless steel pipe heater |
| Interior Material | Stainless steel |
| Exterior Material | Cold-rolled steel plate with melamine resin baked finish |
| Heat Insulation | Glass wool |
| Operating Temperature Range | ambient +30 to 360°C *1 |
| Material | Chrome free electrogalvanized carbon steel sheet metal, finished in chemical-proof, baked-on coating (exterior) Stainless steel sheet metal (interior) |
| Country of Origin | Japan |
| GTIN (Barcode) | 797059926916 |
| Shipping Weight | 800 lbs |
| Dimensions (L × W × H) | 52 × 35 × 76 in |
| Component Size | 91 L |
*1 No-load operation of bath only; maximum temperature varies with circumstances and operating conditions. *2 Measured under ambient temperature 23°C ±5°C, humidity 65%RH ±20%, per Yamato Scientific test conditions.
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| DT-411 | EA | EA |
Documentation
More in This Series
- Clean Oven 91L 3 Phase
- Clean Oven 216L 3 Phase
- Clean Oven 216L 3 Phase
- Large Capacity Clean Oven 327L 3 Phase. Temp Range From +30°C To 260°C
- Large Capacity Clean Oven 327L 3 Phase. Temp Range From +30°C To 360°C
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so every DT411 ships as a genuine factory unit backed by the manufacturer warranty. Our lab-equipment specialists can answer spec questions before you place the order.
- Authorized Yamato Scientific dealer — genuine unit with full manufacturer warranty.
- In stock and ready to order direct.
- Ships from USA inventory.
- Dedicated lab-equipment specialists available for technical and spec questions.
Frequently Asked Questions
What is the temperature range of the Yamato DT411 clean oven?
The DT411 operates from ambient +30°C up to a maximum of 360°C. This forced-convection range supports curing, drying, and burn-in protocols that require elevated, controlled heat.
What is the chamber capacity and overall footprint?
The chamber holds 91 L. The unit measures 52 × 35 × 76 inches (L × W × H) and weighs approximately 800 lbs, so plan floor space and circuit access accordingly.
What power supply does the DT411 require?
The DT411 runs on a 220V 3-phase supply. A built-in phase-reversal relay detects an incorrect power source at installation, so confirm your site service matches before setup.
What materials are used in the chamber construction?
The interior is stainless steel sheet metal. The exterior is chrome-free electrogalvanized carbon steel finished in a chemical-proof, baked-on coating.
What cleanliness class does this oven achieve?
The DT411 is a Class 100 clean oven using forced convection. It is designed for temperature testing in dust-free environments where particulate contamination must be controlled.
Does the DT411 come with certification documentation?
Yes. The oven is manufactured in Japan under ISO 9001:2015 and ISO 14001:2015 certified processes, with certification documents available to support your quality records.
