Clean Oven 216L 3 Phase Overview
The Clean Oven 216L 3 Phase (Yamato Scientific DE611) is a Class 100 forced-convection clean oven built for dust-free heat processing across an operating range of ambient +30 to 260°C, with 216 liters of chamber capacity. LabSupplies.com supplies this unit as an authorized Yamato Scientific dealer.
Forced convection paired with HEPA filtration maintains a Class 100 environment inside the chamber. Exterior panels use chrome-free electrogalvanized carbon steel sheet metal finished in a chemical-proof, baked-on coating, while interior surfaces are stainless steel sheet metal for cleanability and chemical tolerance.
Power is 220V three-phase, suited to facilities with industrial circuits. Footprint measures 58 × 46 × 82 inches and the unit weighs 1,012 lbs, so floor placement should account for that mass. Manufactured in Japan and backed by ISO 9001:2015 and ISO 14001:2015 certifications.
Key Features
- Class 100 clean environment: forced-convection airflow with HEPA filtration supports dust-free temperature testing and processing.
- V-type controller: improves visibility and operability, displaying power consumption, CO2 emissions, and heater manipulated variables on the control panel.
- Filter status indication: three-color HEPA indicator makes replacement timing easy to read at a glance.
- Phase-reversal protection: a phase-reversal relay detects an incorrect power source at installation, adding electrical safety.
- Anti-fouling casters: mobility without wheel contamination during transport between rooms.
- Larger φ33mm cable port: accommodates wiring and instrumentation lead-throughs for in-chamber testing.
How to Choose the Right Clean Oven
A clean oven selection balances chamber size, thermal range, cleanliness class, and the electrical service available at your facility. Match each axis to the application .
- Capacity: 216 liters sets how many parts, fixtures, or batch loads fit per cycle; size to peak throughput, not average.
- Temperature range: an ambient +30 to 260°C window must cover your highest process setpoint with margin.
- Cleanliness class: Class 100 forced convection suits dust-sensitive testing; confirm your protocol requires that level.
- Voltage and power: this unit needs 220V three-phase service, so verify the circuit exists before delivery.
- Footprint and weight: a 58 × 46 × 82 inch, 1,012 lb unit requires a planned floor location and access path.
- Safety features: phase-reversal detection and filter indicators reduce installation and maintenance risk.
Specifications
| Specification | Detail |
|---|---|
| Capacity | 216 L |
| Max Temperature | 260°C |
| Voltage | 220V |
| Power | 3 Phase |
| Circulation Method | Forced convection |
| Temperature Accuracy | ±0.3°C (at 260°C) *2 |
| Temperature Fluctuation | ±0.5°C (at 260°C) |
| Temperature Distribution | ±2.5°C (at 260°C) *2 |
| Clean Level | Class 100 (at stable temperature) |
| Filter | Heat-resistant HEPA filter (>99.97% at 0.3 µm) |
| Temperature Control System | PID-V control |
| Heater | Stainless steel pipe heater |
| Interior Material | Stainless steel |
| Exterior Material | Cold-rolled steel plate with melamine resin baked finish |
| Heat Insulation | Glass wool |
| Operating Temperature Range | ambient +30 to 260°C *1 |
| Material | Chrome free electrogalvanized carbon steel sheet metal, finished in chemical-proof, baked-on coating (exterior) Stainless steel sheet metal (interior) |
| Country of Origin | Japan |
| GTIN (Barcode) | 797059926909 |
| Shipping Weight | 1012 lbs |
| Dimensions (L × W × H) | 58 × 46 × 82 in |
| Component Size | 216 L |
*1 No-load operation of bath only; maximum temperature varies with circumstances and operating conditions. *2 Measured under ambient temperature 23°C ±5°C, humidity 65%RH ±20%, per Yamato Scientific test conditions.
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| DE-611 | EA | EA |
Documentation
More in This Series
- Clean Oven 91L 3 Phase
- Clean Oven 91L 3 Phase
- Clean Oven 216L 3 Phase
- Large Capacity Clean Oven 327L 3 Phase. Temp Range From +30°C To 260°C
- Large Capacity Clean Oven 327L 3 Phase. Temp Range From +30°C To 360°C
Why Buy From LabSupplies.com
LabSupplies.com sells the Yamato Scientific DE611 as an authorized dealer, so every unit is genuine and carries the manufacturer warranty. Order directly and our lab-equipment specialists can answer specification questions before you commit.
- Authorized Yamato Scientific dealer: genuine equipment with full manufacturer warranty.
- In stock: ready to order without waiting on backorder.
- Ships from USA inventory: domestic fulfillment from LabSupplies.com.
- Specialist support: dedicated lab-equipment specialists for spec and configuration questions.
Frequently Asked Questions
What is the operating temperature range of the Yamato DE611 clean oven?
The DE611 operates from ambient +30°C up to a maximum of 260°C. Its forced-convection design holds temperature within a Class 100 clean environment for dust-free processing.
How large is the chamber and what is the unit's footprint?
The chamber capacity is 216 liters. External dimensions measure 58 × 46 × 82 inches (L×W×H), and the unit weighs 1,012 lbs, so plan a dedicated floor location.
What power supply does the DE611 require?
The DE611 requires 220V three-phase power. A phase-reversal relay detects an incorrect power source at installation, helping prevent wiring errors during setup.
What materials are used in the oven's construction?
The interior is stainless steel sheet metal for chemical tolerance and cleanability. Exterior panels are chrome-free electrogalvanized carbon steel finished in a chemical-proof, baked-on coating.
How does the controller help monitor operation?
The V-type controller improves visibility and operability. It displays power consumption, CO2 emissions, and heater manipulated variables directly on the control panel for at-a-glance monitoring.
Is the DE611 certified and where is it made?
The DE611 is manufactured in Japan by Yamato Scientific. Production is backed by ISO 9001:2015 and ISO 14001:2015 certifications, with documentation available.
