Sterilizer Without Dryer 47L 200 Overview
The Sterilizer Without Dryer 47L 200 (model SN510C) is a 47-liter standard steam sterilizer in the autoclave category, operating across a 45 to 135°C range. Top loading simplifies sample handling, while the 135°C maximum supports protein modification alongside routine sterilization of culture mediums and liquids.
Chamber and cover use stainless steel SUS304 for corrosion resistance under repeated steam cycles. Exterior panels are built from bonderizing steel plate baked with melamine resin coating and ABS resin, giving the unit a durable, wipe-clean surface for shared lab environments.
This SN510C runs on a 220V supply and ships configured for steam sterilization without an integrated dryer. Footprint measures 29 × 23 × 51 inches, and the unit weighs 287 lbs with mobility wheels for repositioning. Manufacturing is backed by CE certification and ISO 9001:2015, ISO 14001:2015, and ISO 45001:2018 management systems.
Key Features
- Top-loading chamber: easy sample loading and ergonomic handling within the 47 L capacity.
- 135°C maximum temperature: handles ordinary sterilization, culture medium and liquid sterilization, plus medium melting.
- Custom program storage: save frequently used cycles for repeatable, one-touch operation.
- Timer start and pre-heating: schedule runs and reach setpoint faster for efficient time use.
- Cooling fan: shortens cool-down time between cycles.
- Mobile design: wheels allow the unit to be moved across the lab as workflows shift.
How to Choose the Right Sterilizer / Autoclave
Matching an autoclave to your workflow means weighing chamber size against throughput, then confirming the unit reaches the temperatures your protocols demand on the power available at your site. Use the criteria below to narrow the decision.
- Capacity: chamber volume sets batch size; 47 L suits mid-volume labs running glassware, media, and liquids.
- Temperature range: a 135°C ceiling covers routine loads and protein-modification work that lower-rated units cannot reach.
- Control type: programmable cycle storage reduces operator error and speeds repeat runs.
- Voltage: confirm site power matches the unit; this model requires 220V.
- Footprint and mobility: verify bench or floor clearance against the 29 × 23 × 51 in dimensions, and note the 287 lb weight on wheels.
- Safety and compliance: CE and ISO certifications signal documented manufacturing and quality controls.
Specifications
| Specification | Detail |
|---|---|
| Capacity | 47 L |
| Voltage | 220V |
| System | Automatic high-pressure steam sterilizer |
| Operating Temperature Range | 45 to 135°C *1 |
| Max. Operating Pressure | 0.255 MPa |
| Temperature Control System | PID control by microprocessor |
| Lid | Manual upward-opening with safety interlock |
| Operation Modes | Instrument, liquid, sterilize-and-keep-warm, melt-and-keep-warm, and custom-programmed courses |
| Safety Devices | Sensor-failure detection; SSR short-circuit; broken-heater detection; idle-heating prevention; drain-bottle absence alarm; lid-lock failure detection; pressure relief valve (0.255 MPa) |
| Cooling | Axial fan motor with forced cooling |
| Internal Capacity | 47 L |
| Internal Dimensions | ø300 × D665 mm |
| Heater | 950 W × 2 |
| Material | Bonderizing steel plate baked with melamine resin coating, ABS resin (exterior) Stainless steel SUS304 (chamber/cover) |
| Country of Origin | China |
| GTIN (Barcode) | 797059927159 |
| Shipping Weight | 287 lbs |
| Dimensions (L × W × H) | 29 × 23 × 51 in |
| Component Size | 47 L |
*1 No-load operation of bath only; maximum temperature varies with circumstances and operating conditions.
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| SN-510C | EA | EA |
Documentation
- Product Brochure
- ISO 9001
- ISO 14001
- ISO 45001
- CE Certification
- Yamato Scientific Official Product Page
More in This Series
- Compact Sterilizer 18L
- Compact Sterilizer 24L
- Compact Sterilizer 30L
- Sterilizer Without Dryer 32L
- Sterilizer Without Dryer 47L
- Large Capacity Sterilizer Without Dryer 50L
- Large Capacity Sterilizer Without Dryer 80L
- Large Capacity Sterilizer Without Dryer 110L
- Sterilizer With Dryer 20L
- Sterilizer With Dryer 32L
- Sterilizer With Dryer 47L
- Large Capacity Sterilizer With Dryer 50L
- Large Capacity Sterilizer With Dryer 80L
- Natural Convection Dry Sterilizer 99L
- Natural Convection Dry Sterilizer 162L
- Forced Convection Dry Sterilizer 300L
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so every SN510C arrives as a genuine factory unit backed by the manufacturer warranty. Orders ship directly from USA inventory, and our lab-equipment specialists can answer spec questions before you commit.
- Authorized Yamato Scientific dealer supplying genuine units with manufacturer warranty.
- In stock and ready to ship from USA inventory.
- Dedicated lab-equipment specialists available for technical and configuration questions.
Frequently Asked Questions
What is the temperature range of the SN510C sterilizer?
The SN510C operates from 45 to 135°C. The 135°C maximum supports protein modification, ordinary sterilization, sterilization of culture mediums and liquids, and medium melting.
What is the chamber capacity and footprint?
Capacity is 47 liters. External dimensions measure 29 × 23 × 51 inches (L × W × H), and the unit weighs 287 lbs with mobility wheels for repositioning.
What voltage does this sterilizer require?
The SN510C requires a 220V supply. Confirm your site power matches before installation.
What materials are used in construction?
The chamber and cover are stainless steel SUS304 for corrosion resistance. Exterior panels use bonderizing steel plate baked with melamine resin coating plus ABS resin for a durable, cleanable surface.
Can sterilization cycles be saved and reused?
Yes. Custom programs can be stored for repeated, one-touch use, and timer start plus pre-heating features streamline scheduling and time efficiency.
Is this unit certified and is it mobile?
The SN510C carries CE certification and is manufactured under ISO 9001:2015, ISO 14001:2015, and ISO 45001:2018 systems. It is mounted on wheels for easy movement within the lab.
