Remote Dispense - With Uv, Uf And Toc Monitor Installed, /50Hz Overview
The Remote Dispense - With Uv, Uf And Toc Monitor Installed, /50Hz (model WG311UVUFTR) is a Type I water purification system from Yamato Scientific, sold by LabSupplies.com as an authorized dealer. This compact unit delivers 18.2 MΩ·cm ultrapure water at TOC below 5 ppb, serving genetics testing and biological work that demand low-organic, high-resistivity feed.
Purification combines conditioning and polishing cartridges with UV oxidation and ultrafiltration, sterilizing bacteria, reducing TOC, and removing pyrogens ahead of a 0.2 µm final filter. Quick-change cartridges use a no-tools design built around premium ResinTech ion-exchange media. Real-time quality monitoring with integrated leak detection tracks output continuously.
Power runs on 220V / 50 Hz. Footprint measures 21.6 × 14.7 × 14.4 inches (54.8 × 37 × 36.5 cm), and the system weighs 51 lbs. Manufactured in the USA, this purifier uses a remote dispense configuration for flexible point-of-use placement.
Key Features
- Type I ultrapure output: 18.2 MΩ·cm resistivity with TOC below 5 ppb for genetics and biological applications.
- Multi-stage purification: conditioning and polishing cartridges plus UV oxidation, ultrafiltration, and a 0.2 µm final filter for bacteria sterilization, TOC reduction, and pyrogen removal.
- Bacteria control: delivers water at less than 1 cfu/ml.
- Typical flow rate: 2.5 LPM (0.67 GPM) from a feed supply rated under 20 µS/cm.
- Quick-change cartridges: no-tools design using premium ResinTech ion-exchange media.
- Integrated monitoring: real-time TOC monitor with leak detection for continuous output assurance.
How to Choose the Right Water Purification System
Selecting a lab water system starts with the purity grade your workflow requires, then the practical fit of the unit to your bench, feed supply, and electrical service. Match these axes to your application .
- Water quality grade: Type I ultrapure (18.2 MΩ·cm) suits genetics, molecular biology, and other organic-sensitive work, while less demanding tasks may accept lower grades.
- TOC and contaminant control: confirm that UV oxidation, ultrafiltration, and TOC monitoring meet your organic, bacteria, and pyrogen targets — this unit holds TOC below 5 ppb and bacteria under 1 cfu/ml.
- Dispense configuration: a remote dispense layout separates the point of use from the unit body, freeing bench space and improving ergonomics.
- Voltage and frequency: verify your facility supports the system's power input — this model runs on 220V / 50 Hz.
- Feed water quality: ensure your supply meets the requirement of less than 20 µS/cm for reliable performance and cartridge life.
- Footprint: confirm bench clearance for the 21.6 × 14.7 × 14.4 inch enclosure.
Specifications
| Specification | Detail |
|---|---|
| Voltage | 220V |
| Type | Type I ultrapure water purification system |
| Purification Process | Conditioning and polishing cartridges plus UV oxidation and ultrafiltration (bacteria sterilization, TOC reduction, pyrogen removal), with a 0.2 µm final filter |
| TOC | < 5 ppb |
| TOC Monitor | Integrated TOC monitor |
| Dispense Configuration | Remote dispense |
| Power | 220V / 50 Hz |
| Application | Genetics testing and biological work — ultrapure, biological, low TOC |
| Water Quality | Type I ultrapure — 18.2 MΩ·cm resistivity |
| Bacteria | < 1 cfu/ml |
| Flow Rate | 2.5 LPM / 0.67 GPM (typical) |
| Feed Water Requirement | < 20 µS/cm |
| Final Filter | 0.2 micron |
| Monitoring | Real-time quality monitoring with leak detection |
| Cartridges | Quick-change, no-tools design; premium ResinTech ion-exchange media |
| Dimensions (H × W × D) | 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) in |
| Country of Origin | United States |
| GTIN (Barcode) | 797059929498 |
| Shipping Weight | 51 lbs |
| Dimensions (L × W × H) | 26.5 × 26.63 × 20.3 in |
| ISO 9001:2015 | Contact Customer Service |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| WG-311UVUFTR | EA | EA |
Documentation
More in This Series
- Distilled / Deionized Water Purification System ~1.8L/Hr. 20L Tank With External Transformer
- Distilled / Deionized Water Purification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Waterpurification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank Single Phase With External Transformer
- Deionized Water Purification System 0.5~1.0L/Min 115
- Benchtop Or Wall Mount Base System, /60Hz
- Benchtop Or Wall Mount Base System, /50Hz
- Remote Dispense Configuration Base System, /60Hz
- Remote Dispense Configuration Base System, /50Hz
- Benchtop - With Uv Oxidation Lamp Installed, /60Hz
- Benchtop - With Uv Oxidation Lamp Installed, /50Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /60Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /50Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Benchtop - With Ultrafiltration Module, /60Hz
- Benchtop - With Ultrafiltration Module, /50Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /60Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /50Hz
- Benchtop - With Uv And Uf Installed, /60Hz
- Benchtop - With Uv And Uf Installed, /50Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /60Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /50Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /60Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /50Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /60Hz
- Direct Feed Option (Factory Installed)
- Wall Mount Bracket
- Dispensing Gun Option (Factory Installed)
- High Purity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
- High Purity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so every WG311UVUFTR ships as a genuine factory unit backed by the manufacturer warranty. Order directly and our lab-equipment specialists stand by for any specification question.
- Authorized Yamato Scientific dealer: genuine equipment with full manufacturer warranty.
- In stock: ready to ship from USA inventory.
- Made in USA: manufactured domestically per the product data.
- Specialist support: dedicated lab-equipment experts for spec and configuration questions.
Frequently Asked Questions
What water quality does the WG311UVUFTR produce?
It produces Type I ultrapure water at 18.2 MΩ·cm resistivity. TOC stays below 5 ppb and bacteria below 1 cfu/ml, supporting genetics testing and biological work.
What voltage and frequency does this system require?
The WG311UVUFTR runs on 220V / 50 Hz. Confirm your facility supplies matching power before installation.
What is the footprint and weight of the unit?
The enclosure measures 21.6 × 14.7 × 14.4 inches (54.8 × 37 × 36.5 cm) and the system weighs 51 lbs. Verify bench clearance and support before placement.
How does the purification process remove contaminants?
The system uses conditioning and polishing cartridges with UV oxidation and ultrafiltration, sterilizing bacteria, reducing TOC, and removing pyrogens. A 0.2 µm final filter polishes the output before dispensing.
What feed water and flow rate should I expect?
Feed water must be less than 20 µS/cm. Typical dispense flow is 2.5 LPM (0.67 GPM).
Does this model include TOC monitoring?
Yes. An integrated TOC monitor provides real-time quality readings, and leak detection tracks the system continuously during operation.
