Benchtop - With Uv, Uf And Toc Monitor Installed, /50Hz Overview
The Benchtop - With Uv, Uf And Toc Monitor Installed, /50Hz (model WG311UVUFTB) is a Type I ultrapure water purification system from Yamato Scientific. It delivers 18.2 MΩ·cm resistivity water with TOC below 5 ppb. LabSupplies.com, authorized dealer, stocks this 220V/50Hz unit for genetics testing and demanding biological work.
Purification combines conditioning and polishing cartridges with UV oxidation and ultrafiltration. This sequence handles bacteria sterilization, TOC reduction, and pyrogen removal before a 0.2 micron final filter. Quick-change cartridges use a no-tools design with premium ResinTech ion-exchange media. Real-time quality monitoring with leak detection guards every dispense.
Power runs on 220V at 50 Hz, suited to international or matched lab circuits. A compact 21.6 × 14.7 × 14.4 inch body installs on a bench or as a wall mount. Manufactured in the US, the unit ships at 37.4 lbs. ISO 9001:2015 status is available through customer service.
Key Features
- Type I ultrapure output: 18.2 MΩ·cm resistivity, TOC under 5 ppb, and bacteria below 1 cfu/ml for sensitive biological and genetics work.
- Multi-stage purification: UV oxidation plus ultrafiltration with a 0.2 micron final filter for sterilization, TOC reduction, and pyrogen removal.
- Integrated TOC monitor: real-time water-quality monitoring with leak detection tracks performance during operation.
- Quick-change cartridges: no-tools cartridge design using premium ResinTech ion-exchange media for fast maintenance.
- Flexible dispensing: benchtop or wall-mount installation fits crowded lab footprints.
- Stable supply: typical 2.5 LPM (0.67 GPM) flow from feed water under 20 µS/cm.
How to Choose the Right Water Purification System
Match the system to your application's purity grade, throughput, and bench constraints before specifying a model. Use these criteria to narrow the decision.
- Water quality grade: Type I ultrapure (18.2 MΩ·cm) suits genetics, cell culture, and trace analysis, while lower grades fit general rinsing.
- TOC control: an integrated TOC monitor and UV oxidation matter when organic contamination would compromise sensitive assays.
- Flow rate: confirm typical dispense (here 2.5 LPM) covers peak demand without bottlenecking workflows.
- Feed water requirement: verify your source meets the inlet spec (under 20 µS/cm) for stable performance.
- Footprint and mounting: benchtop or wall-mount flexibility helps when bench space is limited.
- Voltage: match the 220V/50 Hz supply to your facility's available circuit.
Specifications
| Specification | Detail |
|---|---|
| Voltage | 220V |
| Type | Type I ultrapure water purification system |
| Purification Process | Conditioning and polishing cartridges plus UV oxidation and ultrafiltration (bacteria sterilization, TOC reduction, pyrogen removal), with a 0.2 µm final filter |
| TOC | < 5 ppb |
| TOC Monitor | Integrated TOC monitor |
| Dispense Configuration | Benchtop or wall-mount |
| Power | 220V / 50 Hz |
| Application | Genetics testing and biological work — ultrapure, biological, low TOC |
| Water Quality | Type I ultrapure — 18.2 MΩ·cm resistivity |
| Bacteria | < 1 cfu/ml |
| Flow Rate | 2.5 LPM / 0.67 GPM (typical) |
| Feed Water Requirement | < 20 µS/cm |
| Final Filter | 0.2 micron |
| Monitoring | Real-time quality monitoring with leak detection |
| Cartridges | Quick-change, no-tools design; premium ResinTech ion-exchange media |
| Dimensions (H × W × D) | 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) in |
| Country of Origin | United States |
| GTIN (Barcode) | 797059929450 |
| Shipping Weight | 37.4 lbs |
| Dimensions (L × W × H) | 26.5 × 18.63 × 20.3 in |
| ISO 9001:2015 | Contact Customer Service |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| WG-311UVUFTB | EA | EA |
Documentation
More in This Series
- Distilled / Deionized Water Purification System ~1.8L/Hr. 20L Tank With External Transformer
- Distilled / Deionized Water Purification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Waterpurification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank Single Phase With External Transformer
- Deionized Water Purification System 0.5~1.0L/Min 115
- Benchtop Or Wall Mount Base System, /60Hz
- Benchtop Or Wall Mount Base System, /50Hz
- Remote Dispense Configuration Base System, /60Hz
- Remote Dispense Configuration Base System, /50Hz
- Benchtop - With Uv Oxidation Lamp Installed, /60Hz
- Benchtop - With Uv Oxidation Lamp Installed, /50Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /60Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /50Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Benchtop - With Ultrafiltration Module, /60Hz
- Benchtop - With Ultrafiltration Module, /50Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /60Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /50Hz
- Benchtop - With Uv And Uf Installed, /60Hz
- Benchtop - With Uv And Uf Installed, /50Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /60Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /60Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /50Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /60Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /50Hz
- Direct Feed Option (Factory Installed)
- Wall Mount Bracket
- Dispensing Gun Option (Factory Installed)
- High Purity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
- High Purity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
Why Buy From LabSupplies.com
Procurement teams order the WG311UVUFTB directly from LabSupplies.com with confidence in a genuine, fully supported unit.
- Authorized Yamato Scientific dealer: every system is a genuine unit backed by the manufacturer warranty.
- In stock: ready to order now, no waitlist.
- Ships from USA inventory: domestic dispatch shortens lead times.
- Lab-equipment specialists: dedicated support answers spec and configuration questions.
Frequently Asked Questions
What water quality does the WG311UVUFTB produce?
It produces Type I ultrapure water at 18.2 MΩ·cm resistivity, with TOC below 5 ppb and bacteria under 1 cfu/ml. The combination suits genetics testing and biological applications.
What voltage and power does this system require?
The WG311UVUFTB runs on 220V at 50 Hz. Confirm your facility has a matched circuit before installation.
What are the dimensions and weight of the unit?
The purifier measures 21.6 × 14.7 × 14.4 inches (54.8 × 37 × 36.5 cm) and weighs 37.4 lbs. It installs on a benchtop or as a wall mount.
How does the system reduce TOC and bacteria?
UV oxidation and ultrafiltration handle bacteria sterilization, TOC reduction, and pyrogen removal, followed by a 0.2 micron final filter. An integrated TOC monitor tracks quality in real time.
What feed water and flow rate should I expect?
Feed water must measure under 20 µS/cm. Typical dispense flow is 2.5 LPM (0.67 GPM).
How are the purification cartridges replaced?
Cartridges use a quick-change, no-tools design with premium ResinTech ion-exchange media. The setup simplifies routine maintenance for lab staff.
