Remote Dispense Configuration Base System, /60Hz Overview
The Remote Dispense Configuration Base System (Yamato Scientific WA301R) is a Type I water purification system that produces 18.2 MΩ·cm ultrapure water on demand. LabSupplies.com, an authorized Yamato Scientific dealer, supplies this compact unit for labs needing reagent-grade Type I water at the point of use.
Purification runs through conditioning and polishing cartridges followed by a 0.2 µm final filter. Quick-change, no-tools cartridges hold premium ResinTech ion-exchange media. Real-time quality monitoring with leak detection tracks output, while the remote dispense layout separates the dispense point from the base for flexible bench placement.
Power draw is 120V/60Hz on a standard 115V circuit. Footprint measures 21.6" × 14.7" × 14.4", and the system weighs 42.1 lbs. Built in the US, the WA301R targets a low cost of ownership for routine ultrapure water production.
Key Features
- Type I water quality: delivers 18.2 MΩ·cm resistivity ultrapure water with TOC below 15 ppb and bacteria under 1 cfu/ml.
- Remote dispense configuration: dispense point is separated from the base unit for flexible point-of-use placement.
- Quick-change cartridges: no-tools conditioning and polishing cartridges use premium ResinTech ion-exchange media.
- 0.2 micron final filter: a final polishing filter supports low-bacteria, particle-controlled output.
- Real-time monitoring: built-in quality monitoring with leak detection tracks performance during operation.
- Typical flow rate: 2.5 LPM (0.67 GPM) from feed water below 20 µS/cm conductivity.
How to Choose the Right Water Purification System
Selecting a purification system starts with the water grade your protocols demand, then the volume, feed quality, and bench layout your lab can support. Match these axes to your workflow before ordering.
- Water quality grade: Type I (18.2 MΩ·cm) suits HPLC, molecular biology, and trace analysis; confirm your assays require ultrapure rather than Type II or III.
- Flow rate: a typical 2.5 LPM output covers on-demand reagent water; verify it meets your peak draw needs.
- Feed water requirement: this system expects feed below 20 µS/cm, so check your pretreated source conductivity.
- Dispense configuration: a remote dispense layout lets you place the outlet away from the base, freeing bench space.
- Voltage and power: 120V/60Hz runs on a standard 115V North American circuit.
- Footprint: the 21.6" × 14.7" × 14.4" base must fit your available bench area.
Specifications
| Specification | Detail |
|---|---|
| Voltage | 115V |
| Type | Type I ultrapure water purification system |
| Purification Process | Conditioning and polishing cartridges with a 0.2 µm final filter |
| TOC | < 15 ppb |
| TOC Monitor | Not included |
| Dispense Configuration | Remote dispense |
| Power | 120V / 60 Hz |
| Application | General Type I reagent water on demand |
| Water Quality | Type I ultrapure — 18.2 MΩ·cm resistivity |
| Bacteria | < 1 cfu/ml |
| Flow Rate | 2.5 LPM / 0.67 GPM (typical) |
| Feed Water Requirement | < 20 µS/cm |
| Final Filter | 0.2 micron |
| Monitoring | Real-time quality monitoring with leak detection |
| Cartridges | Quick-change, no-tools design; premium ResinTech ion-exchange media |
| Dimensions (H × W × D) | 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) in |
| Country of Origin | United States |
| GTIN (Barcode) | 797059929283 |
| Shipping Weight | 42.1 lbs |
| Dimensions (L × W × H) | 26.5 × 26.63 × 20.3 in |
| ISO 9001:2015 | Contact Customer Service |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| WA-301R | EA | EA |
Documentation
More in This Series
- Distilled / Deionized Water Purification System ~1.8L/Hr. 20L Tank With External Transformer
- Distilled / Deionized Water Purification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Waterpurification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank Single Phase With External Transformer
- Deionized Water Purification System 0.5~1.0L/Min 115
- Benchtop Or Wall Mount Base System, /60Hz
- Benchtop Or Wall Mount Base System, /50Hz
- Remote Dispense Configuration Base System, /50Hz
- Benchtop - With Uv Oxidation Lamp Installed, /60Hz
- Benchtop - With Uv Oxidation Lamp Installed, /50Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /60Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /50Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Benchtop - With Ultrafiltration Module, /60Hz
- Benchtop - With Ultrafiltration Module, /50Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /60Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /50Hz
- Benchtop - With Uv And Uf Installed, /60Hz
- Benchtop - With Uv And Uf Installed, /50Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /60Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /50Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /60Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /50Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /60Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /50Hz
- Direct Feed Option (Factory Installed)
- Wall Mount Bracket
- Dispensing Gun Option (Factory Installed)
- High Purity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
- High Purity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
Why Buy From LabSupplies.com
LabSupplies.com ships the Yamato Scientific WA301R as a genuine, factory-warrantied unit direct from USA inventory. Order online and our lab-equipment specialists stand by for any specification question before you commit.
- Authorized Yamato Scientific dealer — genuine unit backed by the manufacturer warranty.
- In stock and ready to ship.
- Ships from USA inventory.
- Dedicated lab-equipment specialists available for spec and compatibility questions.
Frequently Asked Questions
What grade of water does the WA301R produce?
It produces Type I ultrapure water at 18.2 MΩ·cm resistivity. Output also delivers TOC below 15 ppb and bacteria under 1 cfu/ml, suiting demanding analytical and molecular applications.
Does the WA301R run on a standard 115V circuit?
Yes. The system operates on 120V/60Hz, compatible with a standard 115V North American outlet, so no special electrical service is required.
What are the dimensions and weight of the base unit?
The base measures 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) and weighs 42.1 lbs. Confirm available bench space before installation.
What feed water does the system require?
Feed water conductivity must be below 20 µS/cm. The unit then delivers a typical flow rate of 2.5 LPM (0.67 GPM) of Type I water.
How is the water purified inside the WA301R?
Water passes through conditioning and polishing cartridges, then a 0.2 micron final filter. Quick-change, no-tools cartridges use premium ResinTech ion-exchange media for easy maintenance.
Is a TOC monitor included with this configuration?
No, a TOC monitor is not included with the base configuration. The system does provide real-time quality monitoring with leak detection during operation.
