Benchtop - With Ultrafiltration Module, /50Hz Overview
The Benchtop - With Ultrafiltration Module, /50Hz (Yamato WB311UFB) is a Type I ultrapure water purification system that delivers 18.2 MΩ·cm resistivity water at a typical 2.5 LPM (0.67 GPM) flow rate. Yamato Scientific engineers this compact unit for labs that need pyrogen-free, nuclease-free water on demand. LabSupplies.com supplies it as an authorized dealer.
An integrated ultrafiltration module pairs with conditioning and polishing cartridges plus a 0.2 micron final filter to remove pyrogens and produce nuclease-free output. Quick-change, no-tools cartridges use premium ResinTech ion-exchange media. Real-time quality monitoring with leak detection tracks output and protects the bench.
Operating on 220V / 50 Hz, the WB311UFB mounts on a benchtop or wall to fit tight footprints. Unit dimensions measure 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm), with a shipping weight of 35.1 lbs. Made in USA. TOC runs below 15 ppb and bacteria below 1 cfu/ml.
Key Features
- Type I ultrapure output: 18.2 MΩ·cm resistivity with TOC below 15 ppb and bacteria below 1 cfu/ml.
- Ultrafiltration module: removes pyrogens and delivers nuclease-free water, backed by a 0.2 micron final filter.
- Quick-change cartridges: no-tools design using premium ResinTech ion-exchange media for conditioning and polishing.
- Real-time monitoring: continuous water-quality readout with integrated leak detection.
- Flexible mounting: benchtop or wall-mount configuration for space-limited labs.
- Typical flow rate: 2.5 LPM (0.67 GPM) from feed water under 20 µS/cm.
How to Choose the Right Water Purification System
Matching a purification system to your protocols starts with the water grade your applications demand and the supporting utilities your bench can provide. Review the axes below before specifying.
- Water type and quality: Type I ultrapure (18.2 MΩ·cm) suits molecular biology, HPLC, and cell culture; confirm your assays require this grade.
- Pyrogen and nuclease control: an ultrafiltration module and 0.2 micron filter matter when downstream work needs pyrogen-free, nuclease-free water.
- Flow rate: a typical 2.5 LPM (0.67 GPM) determines how quickly you can fill vessels for routine throughput.
- Feed water requirement: verify your source stays below 20 µS/cm to maintain rated performance.
- Voltage and power: the 220V / 50 Hz supply must match your facility's available circuit.
- Footprint and mounting: benchtop or wall-mount options fit labs where bench space is limited.
Specifications
| Specification | Detail |
|---|---|
| Voltage | 220V |
| Type | Type I ultrapure water purification system |
| Purification Process | Conditioning and polishing cartridges plus ultrafiltration for pyrogen removal and nuclease-free water, with a 0.2 µm final filter |
| TOC | < 15 ppb |
| TOC Monitor | Not included |
| Dispense Configuration | Benchtop or wall-mount |
| Power | 220V / 50 Hz |
| Application | Type I water requiring pyrogen-free / nuclease-free quality |
| Water Quality | Type I ultrapure — 18.2 MΩ·cm resistivity |
| Bacteria | < 1 cfu/ml |
| Flow Rate | 2.5 LPM / 0.67 GPM (typical) |
| Feed Water Requirement | < 20 µS/cm |
| Final Filter | 0.2 micron |
| Monitoring | Real-time quality monitoring with leak detection |
| Cartridges | Quick-change, no-tools design; premium ResinTech ion-exchange media |
| Dimensions (H × W × D) | 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) in |
| Country of Origin | United States |
| GTIN (Barcode) | 797059929399 |
| Shipping Weight | 35.1 lbs |
| Dimensions (L × W × H) | 26.5 × 18.63 × 20.3 in |
| ISO 9001:2015 | Contact Customer Service |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| WB-311UFB | EA | EA |
Documentation
More in This Series
- Distilled / Deionized Water Purification System ~1.8L/Hr. 20L Tank With External Transformer
- Distilled / Deionized Water Purification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Waterpurification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank Single Phase With External Transformer
- Deionized Water Purification System 0.5~1.0L/Min 115
- Benchtop Or Wall Mount Base System, /60Hz
- Benchtop Or Wall Mount Base System, /50Hz
- Remote Dispense Configuration Base System, /60Hz
- Remote Dispense Configuration Base System, /50Hz
- Benchtop - With Uv Oxidation Lamp Installed, /60Hz
- Benchtop - With Uv Oxidation Lamp Installed, /50Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /60Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /50Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Benchtop - With Ultrafiltration Module, /60Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /60Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /50Hz
- Benchtop - With Uv And Uf Installed, /60Hz
- Benchtop - With Uv And Uf Installed, /50Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /60Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /50Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /60Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /50Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /60Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /50Hz
- Direct Feed Option (Factory Installed)
- Wall Mount Bracket
- Dispensing Gun Option (Factory Installed)
- High Purity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
- High Purity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so every WB311UFB ships as a genuine factory unit with full manufacturer warranty. Our lab-equipment specialists can answer spec questions before you order.
- Authorized Yamato Scientific dealer: genuine unit backed by the manufacturer warranty.
- In stock: ready to ship from USA inventory.
- Made in USA: manufactured in the United States.
- Specialist support: dedicated lab-equipment team for spec and compatibility questions.
Frequently Asked Questions
What water quality does the WB311UFB produce?
It produces Type I ultrapure water at 18.2 MΩ·cm resistivity, with TOC below 15 ppb and bacteria below 1 cfu/ml. The system targets applications requiring pyrogen-free, nuclease-free water.
What voltage and power does the WB311UFB require?
The WB311UFB operates on 220V / 50 Hz. Confirm your facility provides a matching circuit before installation.
What are the unit dimensions and weight?
Unit dimensions are 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm). Shipping weight is 35.1 lbs, and the system mounts on a benchtop or wall.
How does the system achieve pyrogen-free, nuclease-free water?
An ultrafiltration module works with conditioning and polishing cartridges and a 0.2 micron final filter. This combination removes pyrogens and delivers nuclease-free output.
What is the typical flow rate and feed water requirement?
Typical flow rate is 2.5 LPM (0.67 GPM). Feed water should measure below 20 µS/cm to maintain rated performance.
Does the WB311UFB include a TOC monitor?
No, a TOC monitor is not included. The system does provide real-time water-quality monitoring with integrated leak detection.
