Benchtop Or Wall Mount Base System, /50Hz Overview
The Benchtop Or Wall Mount Base System, /50Hz (model WA311B) is a Type I water purification system from Yamato Scientific, supplied by LabSupplies.com as an authorized dealer. This compact unit produces ultrapure reagent water on demand at 18.2 MΩ·cm resistivity for laboratories that need consistent deionized water.
Purification runs through conditioning and polishing cartridges finished by a 0.2 micron final filter. Quick-change, no-tools cartridges carry premium ResinTech ion-exchange media, keeping maintenance fast and cost of ownership low. Typical output reaches 2.5 LPM (0.67 GPM) from feed water under 20 µS/cm.
Operating on 220V / 50 Hz, the system installs on a benchtop or mounts on a wall to suit tight lab footprints. Cabinet dimensions measure 21.6 in × 14.7 in × 14.4 in, and the unit weighs 34.1 lbs. Built in the USA, it includes real-time quality monitoring with leak detection.
Key Features
- Type I ultrapure output: 18.2 MΩ·cm resistivity, TOC below 15 ppb, and bacteria under 1 cfu/ml for demanding reagent-grade applications.
- Quick-change cartridges: no-tools design loaded with premium ResinTech ion-exchange media for fast media swaps.
- 0.2 micron final filter: polishes dispensed water to remove fine particulates and microbial contamination.
- Real-time monitoring: continuous water-quality readout paired with integrated leak detection.
- Flexible installation: benchtop or wall-mount configuration to fit constrained lab spaces.
- Typical 2.5 LPM flow: 0.67 GPM delivery from feed water under 20 µS/cm.
How to Choose the Right Water Purification System
Selecting a purification system starts with the water quality your protocols require, then balances flow, installation space, and site power. Match these axes to your lab before specifying a unit.
- Water quality grade: Type I ultrapure (18.2 MΩ·cm) suits HPLC, molecular biology, and reagent prep; lower grades fit general rinsing. WA311B targets Type I.
- Flow rate: typical 2.5 LPM determines how quickly you can fill large vessels or feed downstream instruments.
- Feed water requirement: the unit expects feed under 20 µS/cm, so confirm your source or pretreatment meets that threshold.
- Installation footprint: benchtop or wall-mount flexibility matters when bench space is limited.
- Voltage and frequency: this model runs on 220V / 50 Hz; verify it matches your facility power.
- Monitoring and maintenance: real-time quality readout, leak detection, and no-tools cartridge changes reduce downtime.
Specifications
| Specification | Detail |
|---|---|
| Voltage | 220V |
| Type | Type I ultrapure water purification system |
| Purification Process | Conditioning and polishing cartridges with a 0.2 µm final filter |
| TOC | < 15 ppb |
| TOC Monitor | Not included |
| Dispense Configuration | Benchtop or wall-mount |
| Power | 220V / 50 Hz |
| Application | General Type I reagent water on demand |
| Water Quality | Type I ultrapure — 18.2 MΩ·cm resistivity |
| Bacteria | < 1 cfu/ml |
| Flow Rate | 2.5 LPM / 0.67 GPM (typical) |
| Feed Water Requirement | < 20 µS/cm |
| Final Filter | 0.2 micron |
| Monitoring | Real-time quality monitoring with leak detection |
| Cartridges | Quick-change, no-tools design; premium ResinTech ion-exchange media |
| Dimensions (H × W × D) | 21.6" × 14.7" × 14.4" (54.8 × 37 × 36.5 cm) in |
| Country of Origin | United States |
| GTIN (Barcode) | 797059929276 |
| Shipping Weight | 34.1 lbs |
| Dimensions (L × W × H) | 26.5 × 18.63 × 20.3 in |
| ISO 9001:2015 | Contact Customer Service |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| WA-311B | EA | EA |
Documentation
More in This Series
- Distilled / Deionized Water Purification System ~1.8L/Hr. 20L Tank With External Transformer
- Distilled / Deionized Water Purification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Waterpurification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank Single Phase With External Transformer
- Deionized Water Purification System 0.5~1.0L/Min 115
- Benchtop Or Wall Mount Base System, /60Hz
- Remote Dispense Configuration Base System, /60Hz
- Remote Dispense Configuration Base System, /50Hz
- Benchtop - With Uv Oxidation Lamp Installed, /60Hz
- Benchtop - With Uv Oxidation Lamp Installed, /50Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /60Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /50Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Benchtop - With Ultrafiltration Module, /60Hz
- Benchtop - With Ultrafiltration Module, /50Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /60Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /50Hz
- Benchtop - With Uv And Uf Installed, /60Hz
- Benchtop - With Uv And Uf Installed, /50Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /60Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /50Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /60Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /50Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /60Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /50Hz
- Direct Feed Option (Factory Installed)
- Wall Mount Bracket
- Dispensing Gun Option (Factory Installed)
- High Purity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
- High Purity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so every WA311B ships as a genuine unit backed by the manufacturer warranty. Order directly and let our lab-equipment specialists handle technical questions before you commit.
- Authorized Yamato Scientific dealer supplying genuine units with full manufacturer warranty.
- In stock and ready to ship from USA inventory.
- Dedicated lab-equipment specialists available for spec and compatibility questions.
- Direct ordering with straightforward fulfillment.
Frequently Asked Questions
What grade of water does the WA311B produce?
It produces Type I ultrapure water at 18.2 MΩ·cm resistivity. TOC stays below 15 ppb and bacteria below 1 cfu/ml, supporting reagent-grade laboratory applications.
What voltage and frequency does the WA311B require?
The system runs on 220V / 50 Hz. Confirm your facility power matches this specification before installation.
Can the WA311B be wall mounted?
Yes. The unit supports both benchtop and wall-mount installation, giving flexibility for labs with limited bench space.
What are the dimensions and weight of the unit?
Cabinet dimensions are 21.6 in × 14.7 in × 14.4 in (54.8 × 37 × 36.5 cm), and the unit weighs 34.1 lbs.
What is the typical flow rate and feed water requirement?
Typical flow is 2.5 LPM (0.67 GPM). Feed water should measure under 20 µS/cm for proper operation.
How are the purification cartridges replaced?
Cartridges use a quick-change, no-tools design loaded with premium ResinTech ion-exchange media, allowing fast swaps with minimal downtime.
