Muffle Furnace With Communication Port 11.3L Overview
The Yamato FO510CR is a 11.3 L muffle furnace with a communication port, built for high-temperature work from 100 to 1150°C: ashing, fusing glass, enamel coatings, ceramics, and soldering and brazing metals. A microprocessor PID controller holds ±2°C at 1150°C, and the firmly sealed chamber door keeps heat in.
The FO510CR is the previous-generation FO model; Yamato's current part number for this size is the FO511CR. It runs on 220V single-phase power (12 A, no plug, round terminal) and stores up to 6 programs. LabSupplies.com is an authorized Yamato Scientific dealer.
Key Features
- Operating range 100 to 1150°C with ±2°C control accuracy (at 1150°C)
- Program operation: up to 6 patterns (30 steps × 1, 15 × 2, or 10 × 3)
- Communication port for connecting the furnace to a PC or data system
- Long-life R-thermocouple sensor and iron-chrome wire heater
- Firmly sealed chamber door for heat tightness; ceramic fiber chamber
- Self-diagnostics, calibration offset, key lock, power-failure recovery, earth leakage breaker and overheat prevention
- Optional exhaust system unit, N₂ gas loading device with flow meter, temperature output terminal, time-up/alarm output terminal, and sample tray
Specifications
| Specification | Detail |
|---|---|
| Capacity | 11.3 L |
| Voltage | 220V single phase, 50/60 Hz |
| Current | 12 A (no plug, round terminal) |
| Heater Output | 2.5 kW |
| Operating Temperature Range | 100 to 1150°C |
| Temperature Control Accuracy | ±2°C (at 1150°C) |
| Exterior Material | Cold rolled steel plate with baked-on melamine resin finish |
| Interior Material | Ceramic fiber |
| Sensor | R-thermocouple |
| Heater | Iron-chrome wire |
| Exhaust Port | ø20 mm (top) |
| Cooling Fan | Axial fan motor |
| Temperature Controller | PID control by microprocessor |
| Setting / Display | Digital setting by ▲/▼ keys, digital display |
| Operation Functions | Fixed temperature, quick auto stop, auto stop, auto start, program |
| Program Capacity | Up to 6 patterns: 30 steps × 1, 15 steps × 2, or 10 steps × 3 |
| Additional Functions | Calibration offset, power failure compensation, key lock |
| Timer | 1 min to 99 h 59 min, and 100 h to 999 h |
| Safety Devices | Self-diagnostics (memory error, heater disconnection, sensor error, SSR short circuit), electric leakage breaker, overheat prevention device |
| Communication | Communication port |
| Included Accessory | Exhaust port cap (1 pc.) |
| Internal Dimensions (W × D × H) | 250 × 300 × 150 mm |
| External Dimensions (W × D × H) | 507 × 504 × 627 mm (20.0 × 19.8 × 24.7 in) |
| Unit Weight | ~44 kg |
| Material (Yamato database) | Steel, Melamine, Epoxy composite resin coating, Stainless steel, SUS304 (body) Ceramic fiber (furnace and door) |
| Country of Origin | China |
| GTIN (Barcode) | 797059927029 |
| Shipping Weight | 175 lbs |
| Shipping Dimensions (L × W × H) | 36 × 36 × 34 in |
| Warranty | 1 year (Yamato Scientific America) |
FO510CR vs. FO511CR: Previous and Current Model
| FO510CR (this model) | FO511CR | |
|---|---|---|
| Part number | FO510CR | FO511CR |
| Generation | Previous | Current |
| Chamber capacity | 11.3 L | 11.3 L |
| Operating range | 100 to 1150°C | 100 to 1150°C |
| Control accuracy | ±2°C (at 1150°C) | ±2°C (at 1150°C) |
| Heater | Iron-chrome wire | Iron-chrome wire (Kanthal AF) |
| Weight | ~44 kg | ~44 kg |
Source: Yamato Scientific FO Series brochures (previous and current models).
Ordering Information
| Catalog number | GTIN / UPC |
|---|---|
| FO-510CR | 797059927029 |
| Manufacturer | Yamato Scientific |
| Manufacturer part number | FO-510CR |
| UNSPSC | 40101805 — Furnaces |
| HTS code | 8514.19.0000 |
| Export classification (ECCN) | EAR99 |
Documents & Downloads
- Yamato FO Series Muffle Furnace (previous models) brochure (PDF, 948 KB)
- Yamato Scientific America product page
More in This Series
- Muffle Furnace With Communication Port 1.5L (FO101CR)
- Muffle Furnace With Communication Port 3.75L (FO201CR)
- Muffle Furnace With Communication Port 7.5L (FO301CR)
- Muffle Furnace With Communication Port 9L (FO411CR)
- Muffle Furnace With Communication Port 11.3L (FO511CR)
- Muffle Furnace With Communication Port 17.5L (FO611CR)
View all Laboratory Muffle Furnaces →
Frequently Asked Questions
What is the difference between the Yamato FO510CR and the FO511CR?
The FO510CR is the previous-generation part number and the FO511CR is Yamato's current model in the same 11.3 L size. Yamato's FO brochures list the same 100–1150°C range, ±2°C accuracy and ~44 kg weight for both; the current model uses a Kanthal AF iron-chrome heater.
What power does the FO510CR need?
220V single phase, 50/60 Hz, 12 A. It ships without a plug (round terminal), so plan for hard wiring or a matching receptacle.
What are the chamber and outside dimensions of the FO510CR?
Internal 250 × 300 × 150 mm (W × D × H), 11.3 L. External 507 × 504 × 627 mm (20.0 × 19.8 × 24.7 in). Unit weight is about 44 kg.
Can the FO510CR run temperature programs?
Yes. It stores up to 6 patterns (30 steps × 1, 15 steps × 2, or 10 steps × 3) and also runs fixed-temperature, quick auto stop, auto stop and auto start modes, with a timer from 1 minute to 999 hours.
What safety features does the FO510CR have?
Self-diagnostics for memory error, heater disconnection, sensor error and SSR short circuit, an electric leakage breaker, an overheat prevention device, key lock and power-failure compensation.
What options are available for the FO510CR?
Yamato lists an exhaust system unit, N₂ gas loading device with flow meter, temperature output terminal, time-up/alarm output terminal, and sample tray.
Where is the Yamato FO510CR manufactured?
Yamato Scientific lists China as the country of origin.
