High Capacity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light) Overview
The High Capacity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light) (model WH501C) from Yamato Scientific is a cartridge deionization water purification system that delivers Type 2 and Type 3 deionized water at the point of use. LabSupplies.com, an authorized dealer, supplies this unit for feed-water polishing and routine lab water demands.
Three treatment stages drive the configuration: a 10" carbon cartridge, two 20" high-capacity DI cartridges, and a 20K DI light monitor. Polypropylene housings carry the 4.5" diameter format. Each stage handles a distinct portion of the contaminant load across the deionization train.
Footprint measures 24.25 × 24.25 × 12 inches, with a shipping weight of 24 pounds. Built in the US, the system is identified by GTIN 797059929573. Electrical ratings for the DI light monitor are available on request — contact for specification.
Key Features
- Three-stage configuration: 10" carbon cartridge, two 20" high-capacity DI cartridges, and a 20K DI light monitor in one system.
- Type 2 and Type 3 output: produces deionized water suitable for general laboratory use and feed-water polishing.
- 4.5" cartridge diameter: high-capacity format engineered for extended service intervals.
- Polypropylene housing: durable filter housing construction for point-of-use installation.
- DI light monitor: 20K DI light provides visual indication of cartridge performance.
- US manufacture: built in the United States and carrying GTIN 797059929573.
How to Choose the Right Water Purification System
Selecting a deionization system starts with the water grade your protocols require, then matches cartridge capacity and footprint to bench or feed-water placement. Weigh these axes before specifying a unit.
- Water quality grade: confirm whether your workflow needs Type 2 or Type 3 water; this model targets both, suiting general lab use and pre-treatment polishing.
- Cartridge capacity: high-capacity 20" DI cartridges extend service life between changeouts, reducing downtime in higher-throughput settings.
- Configuration: a carbon pre-stage ahead of dual DI cartridges addresses both organic load and ion exchange in sequence.
- Footprint: verify the 24.25 × 24.25 × 12 inch envelope fits the intended install location.
- Monitoring: an integrated DI light gives a quick read on output quality without separate instrumentation.
- Power requirements: confirm electrical ratings for the monitor with your facility before install — contact for specification.
Specifications
| Specification | Detail |
|---|---|
| Type | Cartridge deionization (DI) water system |
| Configuration | High-capacity DI cartridge |
| Cartridge Diameter | 4.5" |
| Output Water | Deionized water |
| Application | Point-of-use deionized water; feed-water polishing |
| Material | Polypropylene (filter housing) |
| Country of Origin | United States |
| GTIN (Barcode) | 797059929573 |
| Shipping Weight | 24 lbs |
| Dimensions (L × W × H) | 24.25 × 24.25 × 12 in |
| ISO 9001:2015 | Contact Customer Service |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| WH-501C | EA | EA |
Documentation
More in This Series
- Distilled / Deionized Water Purification System ~1.8L/Hr. 20L Tank With External Transformer
- Distilled / Deionized Water Purification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Waterpurification System ~1.8L/Hr. 30L Tank With External Transformer
- Distilled / Deionized Water Purification System ~5L/Hr. 100L Tank Single Phase With External Transformer
- Deionized Water Purification System 0.5~1.0L/Min 115
- Benchtop Or Wall Mount Base System, /60Hz
- Benchtop Or Wall Mount Base System, /50Hz
- Remote Dispense Configuration Base System, /60Hz
- Remote Dispense Configuration Base System, /50Hz
- Benchtop - With Uv Oxidation Lamp Installed, /60Hz
- Benchtop - With Uv Oxidation Lamp Installed, /50Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Benchtop - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /60Hz
- Remote Dispense Configuration - With Uv Oxidation Lamp, /50Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /60Hz
- Remote Dispense - With Uv Oxidation Lamp And Toc Monitor /50Hz
- Benchtop - With Ultrafiltration Module, /60Hz
- Benchtop - With Ultrafiltration Module, /50Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /60Hz
- Remote Dispense Configuration - With Ultrafiltration Module, /50Hz
- Benchtop - With Uv And Uf Installed, /60Hz
- Benchtop - With Uv And Uf Installed, /50Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /60Hz
- Benchtop - With Uv, Uf And Toc Monitor Installed, /50Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /60Hz
- Remote Dispense Configuration - With Uv And Uf Installed, /50Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /60Hz
- Remote Dispense - With Uv, Uf And Toc Monitor Installed, /50Hz
- Direct Feed Option (Factory Installed)
- Wall Mount Bracket
- Dispensing Gun Option (Factory Installed)
- High Purity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
- High Capacity Di System - 2-1/2" Diameter (10" Carbon, (2) 20" High Capacity Di, & 20 K Di Light)
- High Purity Di System- 4-1/2" Diameter (10" Carbon, (2) 20" Mixed Bed, & 200 K Di Light)
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so every WH501C ships as a genuine unit backed by the manufacturer warranty. Order directly and route spec questions to our lab-equipment specialists.
- Authorized Yamato Scientific dealer: genuine product with full manufacturer warranty.
- In stock: ready to ship, no backorder wait.
- Ships from USA inventory: domestic fulfillment for faster delivery.
- Specialist support: dedicated lab-equipment staff for configuration and spec questions.
Frequently Asked Questions
What water quality does the WH501C produce?
It produces Type 2 and Type 3 deionized water. The system is intended for general laboratory use and feed-water polishing at the point of use.
What cartridges are included in this DI system?
The system includes three stages: one 10" carbon cartridge, two 20" high-capacity DI cartridges, and a 20K DI light monitor. All housings use the 4.5" diameter format.
What are the dimensions and weight of the WH501C?
The unit measures 24.25 × 24.25 × 12 inches and ships at 24 pounds. Confirm the footprint fits your bench or feed-water install location before ordering.
What are the electrical requirements for the DI light monitor?
Electrical ratings are not listed in the available specifications — contact for specification. Our specialists can confirm power requirements with the manufacturer before purchase.
What material is the filter housing made from?
The filter housing is constructed from polypropylene. This material is selected for durability in point-of-use deionization service.
Where is the WH501C manufactured?
It is manufactured in the United States. The system carries GTIN 797059929573 and is identified under UNSPSC code 48101716 for water purifiers.
