Benchtop Vacuum Oven Programmable 27L Overview
The Benchtop Vacuum Oven Programmable 27L (model ADP300C) is a 27 L programmable vacuum drying oven engineered for controlled, low-pressure heat processing across a 40–240°C operating range. Built by Yamato Scientific and supplied by LabSupplies.com as an authorized dealer, this benchtop unit serves labs that need repeatable drying, degassing, and moisture-sensitive curing.
Construction pairs a steel plate SPCC powder-coated exterior with a stainless steel interior chamber for durability and easy cleaning. A silicon rubber door seal blocks air ingress and helps the chamber hold vacuum. Independent overheating prevention protects each circuit, while self-diagnostic functions flag faults during operation.
Available in 115V (ADP300C) and 220V (ADP310C) configurations, the oven occupies a 36 × 36 × 42 in footprint and weighs 195 lbs. Manufacturing is backed by ISO 9001:2015, ISO 14001:2015, and ISO 45001:2018 certified systems. Units ship from USA inventory.
Key Features
- Digital PID controller: supports fixed temperature, quick auto-stop, auto-stop, auto-start, and full program operation.
- Safety systems: self-diagnostic and overheating prevention functions, with an independent overheating prevention device for each circuit.
- Silicon rubber door seal: prevents air leakage and helps maintain chamber vacuum.
- Calibration off-set function: lets users fine-tune temperature accuracy to match reference standards.
- Customizable ports: optional N₂ gas inlet and communication ports adapt the oven to inert-atmosphere and data-logging workflows.
- Stainless steel chamber: 27 L interior resists corrosion and simplifies maintenance.
How to Choose the Right Vacuum Oven
Matching a vacuum oven to your workflow means weighing chamber size, thermal range, and control sophistication against your facility's power and bench space. Use these axes to scope the right unit.
- Capacity: a 27 L chamber suits routine batch drying and degassing; confirm your largest fixture or sample tray fits before ordering.
- Temperature range: the 40–240°C span covers most moisture removal and curing tasks, so verify your process target falls inside it.
- Control type: programmable PID control enables multi-step recipes and auto-start, which matters for repeatable, unattended runs.
- Voltage: select 115V (ADP300C) or 220V (ADP310C) to match the circuit at your installation point.
- Footprint: reserve clearance for the 36 × 36 × 42 in body and its 195 lb weight on a rated bench or stand.
- Safety: per-circuit overheating prevention and self-diagnostics protect samples and staff during long cycles.
Specifications
| Specification | Detail |
|---|---|
| Capacity | 27 L |
| Voltage | 115V |
| Operating Pressure Range | 101 to 0.1 kPa (760 to 1 Torr) |
| Temperature Accuracy | ±1.5°C (at 240°C) *2 |
| Temperature Control System | PID control by microprocessor |
| Sensor | K-thermocouple |
| Heater | Mica heater, 1.05 kW |
| Interior Material | Stainless steel |
| Heat Insulation | Rock wool |
| Observation Window | Tempered glass (12 mm) with polycarbonate resin plate |
| Vacuum Gauge | Bourdon tube type, 0 to 0.1 MPa |
| Max. Temperature Reaching Time | Approx. 100 min |
| Safety Devices | Self-diagnostic functions (heater |
| Shelves | 3 aluminum perforated shelf plates (≈15 kg load each) |
| Material | Steel plate SPCC powder coating (exterior) Stainless steel (interior) |
| Country of Origin | China |
| GTIN (Barcode) | 797059926770 |
| Shipping Weight | 195 lbs |
| Dimensions (L × W × H) | 36 × 36 × 42 in |
| Component Size | 27 L |
*2 Measured under ambient temperature 23°C ±5°C, humidity 65%RH ±20%, per Yamato Scientific test conditions.
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| ADP-300C | 115V | EA |
| ADP-310C | 220V | EA |
Documentation
More in This Series
- Benchtop Vacuum Oven Programmable 10L
- Benchtop Vacuum Oven Programmable 47.2L
- Vacuum Oven Programmable 127.4L
- Vacuum Oven Programmable 264L
- Vacuum Oven Programmable 91L
- Vacuum Oven Programmable 216L
- Large Capacity Vacuum Oven Programmable 512L
- Large Capacity Vacuum Oven Programmable 1000L 3 Phase
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so every ADP300C and ADP310C ships as a genuine factory unit backed by the manufacturer warranty. Order directly and route any specification questions to our lab-equipment team.
- Authorized Yamato Scientific dealer supplying genuine units with manufacturer warranty.
- In stock and ready to ship from USA inventory.
- Dedicated lab-equipment specialists available for configuration and spec questions.
- Backed by Yamato's ISO 9001:2015, ISO 14001:2015, and ISO 45001:2018 certified manufacturing.
Frequently Asked Questions
What is the operating temperature range of the ADP300C vacuum oven?
The ADP300C operates from 40°C to 240°C. This range covers routine moisture removal, degassing, and low-temperature curing in a controlled vacuum environment.
What is the chamber capacity and overall footprint?
The chamber holds 27 L. Overall dimensions are 36 × 36 × 42 in (L × W × H), and the unit weighs 195 lbs, so plan bench clearance and support accordingly.
What is the difference between the ADP300C and ADP310C?
Voltage is the only difference. The ADP300C runs on 115V and the ADP310C runs on 220V; both share the same 27 L capacity, 40–240°C range, and programmable PID control.
What materials are used in the oven construction?
The interior chamber is stainless steel for corrosion resistance and easy cleaning. The exterior is steel plate SPCC with powder coating, and the door uses a silicon rubber seal to maintain vacuum.
What control modes does the oven support?
The digital PID controller supports fixed temperature, quick auto-stop, auto-stop, auto-start, and full program operation. A calibration off-set function allows temperature fine-tuning.
Can the oven be configured for inert-atmosphere or data communication?
Yes. The oven can be customized with an N₂ gas inlet and communication ports, supporting nitrogen purging and external data or control integration.
