The Orbi-Shaker CO2 XL is the large-platform version of Benchmark's in-incubator shaker, with a 16 × 16.5 in platform that takes five 2 L or nine 1 L flasks. It is built for the warmth and up to 100% humidity of a CO2 incubator, and its controls sit on a separate remote module outside the chamber so speed and time can change without opening the door. Speed runs 30–300 rpm on a 19 mm orbit, and the timer spans 1 min to 99 hr or continuous.
Key features
- 16 × 16.5 in platform for five 2 L or nine 1 L flasks
- Remote module stays outside the incubator; flat 1 mm cable
- Withstands humidity up to 100%
- 30–300 rpm on a 19 mm orbit, set in 1 rpm steps
- Non-slip rubber mat platform included; MAGic Clamp optional
Specifications
| Brand | Benchmark Scientific |
|---|---|
| Catalog number | BT4011 / BT4011-E |
| Speed Range | 30–300 rpm |
| Speed Increment | 1 rpm |
| Orbit | 19 mm |
| Timer | 1 min–99 hr or continuous |
| Platform Size | 16 × 16.5 in (40 × 42.5 cm) |
| Flask Capacity | 5 × 2 L or 9 × 1 L |
| Operating Humidity | Up to 100% |
| Dimensions | 17 × 18 × 5 in (43 × 45.75 × 12.7 cm) |
| Weight | 50 lb (23 kg) |
| Cord Length | 60.5 in (154 cm) |
| Electrical | 115 V (BT4011); 230 V (BT4011-E); 50–60 Hz; 50 W |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| BT4011 | 115V, US plug |
| BT4011-E | 230V, European plug |
Accessories listed for this model
| Catalog number | Part |
|---|---|
| BT4010-MR | Benchmark Scientific MAGic Clamp Universal Platform BT4010-MR |
| H1000-MR-25 … | Benchmark Scientific MAGic Clamp Magnetic Flask Clamp H1000-MR Series |
| H1000-MR-CMB | Benchmark Scientific MAGic Clamp COMBO H1000-MR-CMB |
| H1000-MR-MP | Benchmark Scientific MAGic Clamp Microplate Clamp H1000-MR-MP |
| H1000-MR-T500H … | Benchmark Scientific MAGic Clamp Tube Rack H1000-MR Series |
| H1000-P-500 … | Benchmark Scientific Dedicated Flask Platform H1000-P Series |
| H1000-P-MP | Benchmark Scientific Dedicated Microplate Platform H1000-P-MP |
| H1000-P-SP | Benchmark Scientific Universal Spring Platform H1000-P-SP |
| H1010-MR | Benchmark Scientific MAGic Clamp Universal Platform H1010-MR |
Questions about the Orbi-Shaker CO2 XL Orbital Shaker BT4011
What speed range and motion does the Orbi-Shaker CO2 XL Orbital Shaker BT4011 have?
The Orbi-Shaker CO2 XL Orbital Shaker BT4011 runs at 30–300 rpm on a 19 mm orbit, on a 16 × 16.5 in (40 × 42.5 cm) platform.
What accessories are available for the Orbi-Shaker CO2 XL Orbital Shaker BT4011?
Benchmark Scientific lists BT4010-MR (MAGic Clamp Universal Platform), H1000-MR-25 (MAGic Clamp Magnetic Flask Clamp), H1000-MR-CMB (MAGic Clamp COMBO), H1000-MR-MP (MAGic Clamp Microplate Clamp), H1000-MR-T500H (MAGic Clamp Tube Rack) and H1000-P-500 (Dedicated Flask Platform) for the Orbi-Shaker CO2 XL Orbital Shaker BT4011. The full list is in the accessories table on this page.
Is the Orbi-Shaker CO2 XL Orbital Shaker BT4011 available with a European plug?
Yes. BT4011-E is the European-plug version of BT4011: BT4011 is 115V with a US plug and BT4011-E is 230V with a European plug.
