Lab Freezer / Refrigerator Combi 4°C(R), -20°C(F), Auto Defrost,, 23.1 cu.ft. (R) 23.1 cu.ft. (F) Overview
The Lab Freezer / Refrigerator Combi 4°C(R), -20°C(F), Auto Defrost,, 23.1 cu.ft. (R) 23.1 cu.ft. (F) (model RFC1301) is a dual-compartment laboratory combination unit from Yamato Scientific, supplied by LabSupplies.com as an authorized dealer. Each chamber delivers 23.1 cu. ft. of usable capacity. Refrigerator holds 2°C to 8°C; the freezer reaches 0°C to −25°C.
Two independent digital controllers manage each compartment through separate displays for precise monitoring. Three epoxy-coated shelves per chamber organize samples, while polyurethane insulation maintains stable temperatures. Solid locking doors and four locking legs secure inventory and fix the unit in place. Fin-and-tube evaporators paired with automatic defrost reduce manual maintenance across both compartments.
Power runs on 115V, 60 Hz, single-phase, with a NEMA 5-15 plug serving each chamber. The cabinet measures 52 × 34.75 × 81.5 inches and weighs 625 lbs. Built in China and UL listed, it includes audible and visual hi/low temperature alarms plus dry-contact relays. Casters allow relocation within the lab.
Key Features
- Dual independent control: separate digital controllers and displays for the refrigerator and freezer compartments.
- Automatic defrost: both chambers self-defrost to minimize manual upkeep.
- Alarm system: audible and visual hi/low temperature alarms with dry-contact relay outputs for remote monitoring.
- Dedicated compressors: 1/4 hp for the refrigerator and 1/2 hp for the freezer.
- Secure and mobile: two solid locking doors, four locking legs, and casters; UL listed.
- Optional accessories: chart recorder plus leg and wall seismic restraints.
How to Choose the Right Lab Fridge/Freezer Combo
A combination unit consolidates refrigerated and frozen storage into one footprint, so match the specification to your sample load, site power, and compliance needs.
- Capacity: 23.1 cu. ft. per chamber suits labs storing both refrigerated and frozen inventory without two separate cabinets.
- Temperature range: confirm the refrigerator 2°C to 8°C and freezer 0°C to −25°C ranges cover your storage protocols.
- Control type: independent digital controllers let each compartment hold its own setpoint and display.
- Power supply: verify two NEMA 5-15 receptacles on 115V, 60 Hz circuits, since each chamber has its own plug.
- Footprint: plan for a 52 × 34.75 × 81.5 inch cabinet and a 625 lb unit on locking legs.
- Safety and compliance: hi/low alarms and dry-contact relays support temperature monitoring and documentation.
Specifications
| Specification | Detail |
|---|---|
| Capacity | 23.1 cu.ft. |
| Voltage | 115V |
| Defrost | Automatic |
| Refrigerator Temperature Range | 2°C to 8°C / 36°F to 46°F |
| Freezer Temperature Range | 0°C to -25°C / +32°F to -13°F |
| Door | Two solid, locking |
| Shelves | 3 per compartment, epoxy-coated |
| Compressor | 1/4 hp (refrigerator), 1/2 hp (freezer) |
| Interior / Exterior Finish | White coated steel |
| Refrigerator Interior Dimensions | 22" × 28" × 60" |
| Freezer Interior Dimensions | 22" × 28" × 60" |
| Exterior Dimensions | 52" × 34.75" × 81.5" (132 × 88 × 207 cm) |
| Temperature Control | Two independent digital displays |
| Temperature Alarm | Hi/Low temperature, audible and visual; alarm relay dry contacts |
| Evaporator | Fin and tube |
| Refrigerator Defrost | Automatic |
| Freezer Defrost | Automatic |
| Insulation | Polyurethane |
| Legs | Four locking |
| Power Supply | 115V, 60 Hz, 1-phase; NEMA 5-15 plug (one per chamber) |
| Certification | UL listed |
| Optional Accessories | Chart recorder; leg and wall seismic restraints |
| Country of Origin | China |
| Material | Interior Finish Stainless Steel Exterior Finish Stainless Steel |
| GTIN (Barcode) | 797059930289 |
| Shipping Weight | 625 lbs |
| Dimensions (L × W × H) | 56 × 43 × 86 in |
| Component Size | 48 CF |
| Other Certification | UL Listed |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| RFC-1301 | EA | EA |
Documentation
More in This Series
- Lab Freezer / Refrigerator Combi 4°C(R), -20°C(F), Auto Defrost,, 46.6 cu.ft. (R) 23.1 cu.ft. (F)
- Lab Freezer / Refrigerator Combi 4°C(R), -20°C(F), Auto Defrost,, 9.1 cu.ft. (R) 9.1 cu.ft. (F)
View all Lab Refrigerator/Freezer Combinations →
Why Buy From LabSupplies.com
LabSupplies.com ships the Yamato Scientific RFC1301 direct from USA inventory, so your lab gets a genuine, warranty-backed unit without sourcing delays.
- Authorized Yamato Scientific dealer supplying genuine units with manufacturer warranty.
- In stock and ready to ship from USA inventory.
- Lab-equipment specialists available for specification and configuration questions.
- Optional accessories including chart recorder and seismic restraints available on request.
Frequently Asked Questions
What temperature ranges does the RFC1301 hold?
The refrigerator compartment holds 2°C to 8°C (36°F to 46°F) and the freezer holds 0°C to −25°C (+32°F to −13°F). Each compartment uses an independent digital controller and display.
How much storage capacity does each compartment provide?
Each compartment provides 23.1 cu. ft. of capacity, with three epoxy-coated shelves per chamber. The exterior cabinet measures 52 × 34.75 × 81.5 inches.
What electrical supply does the RFC1301 require?
It requires 115V, 60 Hz, single-phase power. Each chamber has its own NEMA 5-15 plug, so two standard receptacles are needed.
Is the RFC1301 UL listed?
Yes, the RFC1301 is UL listed. It also includes audible and visual hi/low temperature alarms with dry-contact relay outputs for remote monitoring.
Does the unit defrost automatically?
Yes, both the refrigerator and freezer compartments use automatic defrost. Fin-and-tube evaporators serve each chamber to reduce manual maintenance.
How is the unit secured and moved?
The unit features two solid locking doors, four locking legs, and casters for relocation. Optional leg and wall seismic restraints are available.
