The R3010 is the 10-roller TubeRoller, doubling the rolling surface of the 5-roller model for larger batches of tubes and bottles. Rollers measure 1.2 × 12.5 in and turn at 2 to 80 rpm while tilting ±5° on every revolution, so contents mix from end to end rather than only rolling. Vessels from 8 to 200 mm in diameter fit, including roller bottles. The unit weighs 17.6 lb and runs at 4°C to 40°C.
Key features
- 10 rollers of 1.2 × 12.5 in
- 2–80 rpm variable rolling speed
- ±5° tilting wave motion on each revolution
- Fits tubes and bottles 8–200 mm in diameter
- 17.6 lb; 115 or 230V, 50W
Specifications
| Brand | Benchmark Scientific |
|---|---|
| Catalog number | R3010 / R3010-E |
| Speed Range | 2–80 rpm (variable) |
| Motion | Simultaneous roll and tilt (±5°) |
| Number of Rollers | 10 |
| Roller Dimensions | 1.2 × 12.5 in (3 × 32 cm) |
| Vessels Accepted | 8–200 mm diameter |
| Operating Temperature | 4–40°C |
| Weight | 17.6 lb (8 kg) |
| Electrical | 115 V or 230 V, 50–60 Hz; 50 W |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| R3010 | 115V, US plug |
| R3010-E | 230V, European plug |
