The Sprint 8 Plus is a benchtop clinical centrifuge with an 8-place fixed-angle rotor that takes 15 mL conical or round-bottom tubes as well as 5/7 mL tubes. Speed is set from 200 to 6,800 rpm or entered directly as RCF up to 4,445 × g, in 10-unit steps, which allows serum or plasma separation in 2–3 minutes. Acceleration and deceleration rates are adjustable, and up to 99 run programs can be stored. The unit weighs 17.6 lb.
Key features
- Speed range 200–6,800 rpm; RCF up to 4,445 × g, set in rpm or RCF
- 8-place fixed-angle rotor for 15 mL conical or round-bottom tubes
- Speed adjustable in 10 rpm or 10 RCF increments
- Stores up to 99 programs; adjustable acceleration and deceleration
- Imbalance detection, electrical lid lock and momentary spin
- Backlit LCD with EZ-Scroll touch pad; 100W draw
Specifications
| Brand | Benchmark Scientific |
|---|---|
| Catalog number | Z207-A / Z207-A-E |
| Speed Range | 200–6,800 rpm |
| Max RCF | 4,445 × g |
| Rotor | 8-place fixed angle |
| Capacity | 8 × 15 mL; 8 × 5/7 mL |
| Speed Increment | 10 rpm or 10 × g |
| Program Storage | Up to 99 |
| Momentary Spin | Yes |
| Safety | Electrical lid lock; imbalance detection |
| Weight | 17.6 lb (8 kg) |
| Electrical | 120 V, US plug (Z207-A); 230 V, European plug (Z207-A-E); 50–60 Hz; 100 W |
Ordering information
| Catalog number | Power |
|---|---|
| Z207-A | 120V, US plug |
| Z207-A-E | 230V, European plug |
Rotors, adapters and accessories listed for this model
| Catalog number | Part |
|---|---|
| Z326-15-A20 | Hermle Adapter for 1.5/2.0 mL Tubes Z326-15-A20 |
