Roto-Therm Plus is the variable speed incubated rotator, turning at 5 to 70 rpm inside a chamber controlled from ambient +5 to 60°C. Mix mode layers oscillation onto rotation, Pause adds periodic stops, and Rock produces a gentle see-saw. Included holders fit tubes from 0.5 to 50 mL; a 4.5 × 3 in. rocking platform and a 96 × 0.2 mL tube, strip and plate holder are also offered. It runs on universal 100–240V power and weighs 10 lb.
Key features
- Variable 5–70 rpm with Mix, Pause and Rock modes
- Chamber temperature ambient +5 to 60°C
- In-lab calibration for temperature accuracy
- Tube holders for 0.5–50 mL
- 96 × 0.2 mL holder for PCR tubes, strips and plates available
- 10 lb; 100–240V, 0.5A
Specifications
| Brand | Benchmark Scientific |
|---|---|
| Catalog number | H2024 / H2024-E |
| Temperature Range | Ambient +5°C–60°C |
| Speed Range | 5–70 rpm (variable) |
| Mixing Modes | Mix (oscillating), Pause, Rock |
| Motion | Adjustable from vertical (end-over-end) to horizontal (rolling) |
| Tube Sizes | 0.5–50 mL |
| Calibration | In-lab calibration function |
| Weight | 10 lb (4.5 kg) |
| Electrical | 100–240 V, 50–60 Hz; 0.5 A |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| H2024 | 100–240V, US plug |
| H2024-E | 100–240V, European plug |
Accessories listed for this model
| Catalog number | Part |
|---|---|
| R2020-150 … | Benchmark Scientific Roto-Mini Tube Holder R2020 Series |
| R2020-RP | Benchmark Scientific Mini Rocking Platform with Rubber Mat R2020-RP |
