The BSH300 is the heating and cooling version of the myBlock Mini, controlling a single exchangeable block from 25°C below room temperature to 100°C. It cools from 20°C to 0°C in under 25 minutes and heats from 20°C to 100°C in under 20 minutes, with ±0.5°C accuracy and uniformity and 0.1°C setpoint resolution. Two consecutive programs can be linked into one run. Blocks for 0.2 mL to 50 mL tubes are sold separately, and the housing measures 4.3 × 6.4 × 5.5 in.
Key features
- Heats and cools from ambient −25°C to 100°C
- Cools from 20°C to 0°C in under 25 minutes
- Heats from 20°C to 100°C in under 20 minutes
- Links two consecutive programs
- Exchangeable 0.2–50 mL tube blocks, sold separately
Specifications
| Brand | Benchmark Scientific |
|---|---|
| Catalog number | BSH300 / BSH300-E |
| Temperature Range | Ambient −25°C – 100°C |
| Temperature Accuracy | ±0.5°C |
| Temperature Uniformity | ±0.5°C |
| Temperature Increments | 0.1°C |
| Heat-Up Time (20°C – 100°C) | < 20 min |
| Cool-Down Time (20°C – 0°C) | < 25 min |
| Block Dimensions | 1.85 × 2.8 × 1.25 in (4.7 × 7.1 × 3.2 cm) |
| Tube Compatibility | 0.2–50 mL tubes (exchangeable blocks, sold separately) |
| Dimensions | 4.3 × 6.4 × 5.5 in (11 × 16.2 × 14 cm) |
| Electrical | 100–240 V, 50–60 Hz; 50 W |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| BSH300 | 100–240V, US plug |
| BSH300-E | 100–240V, European plug |
Questions about the myBlock Mini Dry Bath with Cooling BSH300
What temperature range and accuracy does the myBlock Mini Dry Bath with Cooling BSH300 have?
The myBlock Mini Dry Bath with Cooling BSH300 covers ambient −25°C – 100°C with ±0.5°C accuracy and ±0.5°C uniformity.
Is the myBlock Mini Dry Bath with Cooling BSH300 available with a European plug?
Yes. BSH300-E is the European-plug version of BSH300; both run on 100–240V, so only the plug differs.
