The H5000-H is the heat-only version of the MultiTherm vortex shaker, warming samples from 5°C above ambient to 100°C with 0.1°C resolution and ±1.0°C accuracy. Mixing runs from 200 to 1,500 rpm on a 3 mm orbit, adjustable in 10 rpm steps, and the timer covers 1 minute to 99 h 99 min or continuous operation. Exchangeable blocks for 0.2 mL to 50 mL tubes and plates are ordered separately. The housing measures 8.25 × 11.5 × 8.25 in and weighs 18 lb.
Key features
- Heating from ambient +5°C to 100°C at 5.0°C per minute
- Mixing at 200–1,500 rpm in 10 rpm steps, 3 mm orbit
- Accepts blocks for 0.2–50 mL tubes and plates, up to six 50 mL tubes
- Integral over-temperature control
- 8.25 × 11.5 × 8.25 in (21 × 29 × 21 cm), 18 lb
Specifications
| Brand | Benchmark Scientific |
|---|---|
| Catalog number | H5000-H / H5000-H-E |
| Speed Range | 200–1,500 rpm |
| Speed Increment | 10 rpm |
| Orbit | 3 mm |
| Temperature Range | Ambient +5 °C to 100 °C |
| Temperature Increment | 0.1 °C |
| Temperature Accuracy | ±1.0 °C |
| Capacity | Interchangeable blocks for 0.2–50 mL tubes (sold separately) |
| Heating Rate | 5.0 °C/min |
| Timer | 1 min–99 hr 99 min or continuous |
| Dimensions (W × D × H) | 8.25 × 11.5 × 8.25 in (21 × 29 × 21 cm) |
| Weight | 18 lb (8 kg) |
| Electrical | 115 V (H5000-H); 230 V (H5000-H-E); 50–60 Hz; 500 W |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| H5000-H | 115V, US plug |
| H5000-H-E | 230V, European plug |
