BSH1004 is the four-position model of the Benchmark digital dry bath line, taking up to four interchangeable aluminum blocks in an 8.7 × 14 × 3.2 in housing. Its maximum setpoint is 130°C, lower than the one- and two-block units, with a range starting at ambient +5 and 0.1°C setpoint steps. Temperature is held within ±0.2°C. Blocks for 0.5, 1.5, 2.0, 15 and 50 mL tubes are ordered separately, and a lifter with an insulated handle comes with the bath.
Key features
- Four block positions for higher sample throughput
- Ambient +5 to 130°C maximum on this four-block model
- Holds setpoint within ±0.2°C, set in 0.1°C steps
- 1 to 999 minute countdown timer with alert
- Field recalibration built into the controller
Specifications
| Brand | Benchmark Scientific |
|---|---|
| Catalog number | BSH1004 / BSH1004-E |
| Temperature Range | Ambient +5°C – 130°C |
| Temperature Accuracy | ±0.2°C |
| Temperature Uniformity | ±0.2°C |
| Temperature Increments | 0.1°C |
| Timer | 1–999 min (alert only; does not shut off heater) |
| Block Positions | Four |
| Blocks | Not included (sold separately) |
| Included | Block lifter |
| Dimensions | 8.7 × 14 × 3.2 in (22 × 35.5 × 8 cm) |
| Electrical | 115 V or 230 V |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| BSH1004 | 115V, US plug |
| BSH1004-E | 230V, European plug |
Questions about the Four-Block Digital Dry Bath BSH1004
What temperature range and accuracy does the Four-Block Digital Dry Bath BSH1004 have?
The Four-Block Digital Dry Bath BSH1004 covers ambient +5°C – 130°C with ±0.2°C accuracy and ±0.2°C uniformity.
Is the Four-Block Digital Dry Bath BSH1004 available with a European plug?
Yes. BSH1004-E is the European-plug version of BSH1004: BSH1004 is 115V with a US plug and BSH1004-E is 230V with a European plug.
