The H3770-HS combines heating and magnetic stirring on a 7 × 7 in white ceramic top plate that resists chemical attack. The plate heats from 35 to 400°C and the stir drive runs 150–1,500 rpm, handling up to 5 L of liquid. Both values show on a digital display, and a warning LED lights whenever the plate is above 50°C. With the optional external probe, the controller holds the sample itself within ±1°C; clamp assembly H3770-CS mounts probes and thermometers.
Key features
- 7 × 7 in chemical-resistant white ceramic top plate
- Heats 35–400°C; stirs 150–1,500 rpm
- Stirs volumes up to 5 L
- Hot-surface LED lights above 50°C
- Optional probe holds sample temperature within ±1°C
Specifications
| Brand | Benchmark Scientific |
|---|---|
| Catalog number | H3770-HS / H3770-HS-E |
| Temperature Range | 35–400°C |
| Speed Range | 150–1,500 rpm |
| Platform Dimensions | 7 × 7 in (17.8 × 17.8 cm) |
| Top Plate | White ceramic |
| Max Stirring Volume | 5 L |
| Sample Temperature Control | ±1°C with optional external probe |
| Hot-Surface Indicator | LED, above 50°C |
| Weight | 6.4 lb (2.9 kg) |
| Electrical | 115 V or 230 V |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| H3770-HS | 115V, US plug |
| H3770-HS-E | 230V, European plug |
Accessories listed for this model
| Catalog number | Part |
|---|---|
| H3770-CS | Benchmark Scientific Clamp Set with Support Rod H3770-CS |
| H3770-CSTF | Benchmark Scientific Teflon Clamp Set with Support Rod H3770-CSTF |
| H3770-ROD | Benchmark Scientific Support Rod for Hotplate Stirrer H3770-ROD |
| H3770-TP | Benchmark Scientific Temperature Probe for Hotplate Stirrer H3770-TP |
Questions about the Digital Hotplate Stirrer H3770-HS
How hot does the Digital Hotplate Stirrer H3770-HS get, and how much can it stir?
The Digital Hotplate Stirrer H3770-HS heats over 35–400°C and stirs at 150–1,500 rpm, up to 5 L, on a white ceramic top plate.
What accessories are available for the Digital Hotplate Stirrer H3770-HS?
Benchmark Scientific lists H3770-CS (Clamp Set with Support Rod), H3770-CSTF (Teflon Clamp Set with Support Rod), H3770-ROD (Support Rod for Hotplate Stirrer) and H3770-TP (Temperature Probe for Hotplate Stirrer) for the Digital Hotplate Stirrer H3770-HS.
Is the Digital Hotplate Stirrer H3770-HS available with a European plug?
Yes. H3770-HS-E is the European-plug version of H3770-HS: H3770-HS is 115V with a US plug and H3770-HS-E is 230V with a European plug.
