The W3200-120 is the lowest-capacity Accuris precision balance, weighing up to 120 g with 0.001 g readability, ±0.002 g linearity and ±0.001 g repeatability. Gold-plated ceramic capacitance sensors let it tare and stabilize quickly. A glass draft shield with 3 sliding doors surrounds the 4.5 in (11.5 cm) round pan. Calibration is done in the lab with a calibration weight and a few keystrokes, and results can go to a computer or printer via RS232. Dimensions are 8 × 13.75 × 12.25 in.
Key features
- 120 g x 0.001 g, repeatability ±0.001 g
- Linearity ±0.002 g
- Glass draft shield with 3 sliding doors; 11.5 cm round pan
- Gold-plated ceramic capacitance sensor
- Standard, counting, percent and check-weighing modes in g, oz, ct
- External calibration; RS232 output
Specifications
| Brand | Accuris |
|---|---|
| Catalog number | W3200-120 / W3200-120-E |
| Capacity | 120 g |
| Readability | 0.001 g |
| Linearity | ±0.002 g |
| Repeatability | ±0.001 g |
| Pan Diameter | 4.5 in (11.5 cm) |
| Draft Shield | Glass, 3 sliding doors |
| Calibration | External |
| Weighing Units | g, oz, ct, % |
| Display | Backlit LCD |
| Connectivity | RS232 |
| Dimensions | 8 × 13.75 × 12.25 in (20.5 × 35 × 31 cm) |
| Electrical | 115 V, US plug (W3200-120); 230 V, European plug (W3200-120-E) |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| W3200-120 | 115V, US plug |
| W3200-120-E | 230V, European plug |
