708382SS Stainless Steel Pedestal Eyewash Features
The Global Industrial 708382SS is a free-standing, all-stainless pedestal eyewash station for open floor locations: mid-room lab islands, process floors, chemical dispensing points and wash-down areas away from any wall. Stainless steel pipe, fittings, handle, stay-open ball valve and 11-3/8 inch bowl resist corrosive splash and vapor that would attack a plastic bowl. A push of the handle starts both flip-top spray heads at 5.15 gallons per minute and keeps them running hands-free.
Meets ANSI Z358.1-2014. Ships with an eyewash gauge, plumber's tape and an ANSI identification sign; 1-year limited warranty.
Technical Specifications
| Specification | Detail |
|---|---|
| Manufacturer | Global Industrial |
| Item # | 708382SS |
| Mounting | Pedestal (floor) |
| Pipe & fittings | Stainless steel |
| Bowl | 11-3/8 in stainless steel |
| Spray heads | 2, with flip-top dust covers |
| Activation | Push handle, stainless steel stay-open ball valve |
| Flow rate | 5.15 gal/min |
| Flowing pressure | 30 psi |
| Includes | Eyewash gauge, plumber's tape, ANSI identification sign |
| Weight | 10.6 lb |
| Standard | ANSI Z358.1-2014 |
| Warranty | 1-year limited |
Stainless or Galvanized?
| 708382SS (this unit) | 708382 | |
|---|---|---|
| Pipe | Stainless steel | Schedule 40 galvanized, yellow covers |
| Bowl | 11-3/8 in stainless steel | 11.5 in ABS plastic |
| Best for | Corrosive vapor, wash-down, cleanroom | Dry industrial and lab areas |
The galvanized 708382 pedestal eyewash is the lower-cost option for dry areas. For combined eye and body flushing, see the 708383SS stainless combination shower.
Documents
Frequently Asked Questions
Why choose the 708382SS pedestal over the 708381SS wall unit?
A pedestal eyewash plumbs up through the floor, so it can sit in open floor space or at an island bench where no wall is within the 10-second travel distance ANSI Z358.1-2014 requires. It also allows approach from any side. The 708381SS uses the same stainless bowl and valve but needs a structural wall.
How heavy is the 708382SS and what is included?
The pedestal unit weighs 10.6 pounds. An eyewash gauge, plumber's tape and an ANSI identification sign are included; floor anchors and the supply connection are installed on site.
