60" Wide Vented Balance Enclosure Overview
The 60" Wide Vented Balance Enclosure (models VBE600 and VBE610) from Yamato Scientific is a self-contained balance enclosure engineered for safe weighing of fine powders, chemicals, and biological products. LabSupplies.com, an authorized dealer, supplies this 60-inch-wide unit with top-mounted HEPA/blower filtration that recirculates chamber air through an H14 filter back into the lab.
Optically clear 3/8" jeweled acrylic forms the chamber, paired with a phenolic base that resists chemicals, stabilizes analytical balances, and dampens vibration. Its black base finish makes powder spills easy to spot. Curved ABS airfoils guide gentle, unobstructed flow through rear and side baffles to the H14 HEPA filter, rated 99.9997% at 0.3 microns.
Choose VBE600 for 115–120V service or VBE610 for 220–240V. Each enclosure measures 60.5" × 26.75" × 41" externally and ships at 400 lbs from USA inventory. A face-velocity alarm tracks airflow from 40–2000 fpm with green, yellow, and red indicators. Carries CE certification; manufactured in the USA.
Key Features
- HEPA/blower filtration: top-mounted aluminum-frame H14 HEPA filter, 100 mm pleat, rated 99.9997% at 0.3 microns, with upstream and downstream polyurethane gaskets.
- Construction: optically clear 3/8" jeweled acrylic chamber on a phenolic base for chemical resistance and analytical-balance stabilization.
- Face-velocity alarm: 40–2000 fpm range, sub-1-second response, LED plus audible Piezo, with green (healthy), yellow (turbulence), and red (system failure) indicators.
- Viewing sash and airfoils: front sash with multiple air foils and curved ABS baffles for higher containment and draft deflection.
- Ports: electrical cord outlet port plus a side blank plate that accepts an optional Bag-In/Bag-Out port.
- Voltage options: VBE600 (115–120V) or VBE610 (220–240V), identical in every other specification.
How to Choose the Right Vented Balance Enclosure
Selecting a vented balance enclosure depends on your bench layout, electrical service, and the materials you weigh. Match these axes to your workflow before ordering.
- Voltage: confirm 115–120V (VBE600) or 220–240V (VBE610) matches your facility's electrical service to avoid adapters.
- Footprint: verify the 60.5" wide exterior and 26.75" depth fit your bench; interior width reaches 59.25".
- Filtration: recirculating H14 HEPA suits fine powders and biologicals that need operator protection without external ducting.
- Containment: a front sash, multiple air foils, and a face-velocity alarm matter when handling potent or fine materials.
- Base material: the phenolic base resists chemicals and stabilizes analytical balances against vibration.
- Expansion ports: the side blank plate accepts an optional Bag-In/Bag-Out port for contained filter changes.
Specifications
| Specification | Detail |
|---|---|
| Voltage | 115V |
| Type | Vented balance enclosure |
| Width | 60" |
| Interior Dimensions (W × D × H) | 59.25" × 23" × 21.5" (1505 × 584 × 546 mm) |
| Exterior Dimensions (W × D × H) | 60.5" × 26.75" × 41" (1537 × 679 × 1041 mm) |
| Construction | Optically clear 3/8" jeweled acrylic plastic |
| Filtration | Top-mounted HEPA/blower — aluminum-frame H14 HEPA, 100 mm pleat, 99.9997% @ 0.3 microns, with upstream/downstream polyurethane gasket |
| Base | Phenolic base — superior chemical resistance, analytical-balance stabilization, low vibration; black finish for easy powder detection |
| Viewing Sash | Front viewing sash with multiple air foils for higher containment and draft deflection |
| Airflow Alarm | Face-velocity alarm — 40–2000 fpm range, <1 s response, LED and audible Piezo; green (healthy) / yellow (turbulence) / red (system failure) indicators |
| Draft Protection | Adjustable front draft protection |
| Ports | Electrical cord outlet port; side blank plate for optional Bag-In/Bag-Out port |
| Air Handling | Curved ABS airfoils give gentle, unobstructed flow through rear and side baffles to the top-mounted HEPA filter, recirculating to the lab |
| Power Supply | 115–120V (220–240V variant available) |
| Applications | Self-contained weighing of fine powders, chemicals, and biological products |
| Material | Optically clear 3/8" jeweled acrylic plastic Phenolic base |
| Country of Origin | USA |
| GTIN (Barcode) | 797059929818 |
| Shipping Weight | 400 lbs |
| Dimensions (L × W × H) | 75 × 45 × 51 in |
| Component Size | 60 In |
| CE Certification | CE Certification |
Available Sizes and Configurations
| SKU | Configuration | Pack |
|---|---|---|
| VBE-600 | 115V | EA |
| VBE-610 | 220V | EA |
Documentation
More in This Series
- 48" Wide Vented Balance Enclosure
- 36" Wide Vented Balance Enclosure
- 24" Wide Vented Balance Enclosure
View all Vented Balance Enclosures →
Why Buy From LabSupplies.com
LabSupplies.com is an authorized Yamato Scientific dealer, so every enclosure ships as a genuine unit backed by the manufacturer warranty.
- Authorized Yamato Scientific dealer — genuine units with full manufacturer warranty.
- In stock and ready to ship from USA inventory.
- Lab-equipment specialists available for spec and configuration questions.
- Ships directly to your facility with no third-party sourcing.
Frequently Asked Questions
What is the difference between the VBE600 and VBE610?
The only difference is electrical supply. VBE600 runs on 115–120V, while VBE610 runs on 220–240V. Both share identical 60-inch construction, filtration, dimensions, and containment features.
What are the interior and exterior dimensions?
Interior dimensions are 59.25" × 23" × 21.5" (1505 × 584 × 546 mm). Exterior dimensions are 60.5" × 26.75" × 41" (1537 × 679 × 1041 mm).
What voltage does the enclosure require?
VBE600 requires 115–120V, and VBE610 requires 220–240V. Select the model that matches your facility's electrical service.
What materials are used in construction?
The chamber is optically clear 3/8" jeweled acrylic plastic. The base is phenolic, chosen for chemical resistance, vibration damping, and analytical-balance stabilization.
How does the filtration system work?
A top-mounted HEPA/blower draws chamber air through an aluminum-frame H14 HEPA filter rated 99.9997% at 0.3 microns, then recirculates filtered air back into the lab.
Does the unit include airflow monitoring?
Yes. A face-velocity alarm covers 40–2000 fpm with sub-1-second response, LED and audible Piezo signaling, and green, yellow, and red status indicators.
