Orbi-Shaker CO2-MP mixes microplates inside CO2 incubators, withstanding 0°C to 65°C and humidity up to 100%. A 3 mm orbit at 200–1,200 rpm gives thorough mixing of well plates, with speed set in 1 rpm steps. Speed and time are entered on a remote controller that mounts magnetically to the outside of the incubator, so settings change without opening the chamber. The included six-position platform secures both standard and deep-well plates.
Key features
- Six-position platform for standard or deep-well plates
- 200–1,200 rpm on a 3 mm orbit
- Magnetic-mount remote controller outside the incubator
- Rated for 0°C to 65°C and up to 100% humidity
- Timer 1 min to 99 hr or continuous; 60.5 in (154 cm) cord
Specifications
| Brand | Benchmark Scientific |
|---|---|
| Catalog number | BT4500 / BT4500-E |
| Speed Range | 200–1,200 rpm |
| Speed Increment | 1 rpm |
| Orbit | 3 mm |
| Timer | 1 min–99 hr or continuous |
| Platform Size | 13 × 12 in (33 × 30 cm) |
| Capacity | 6 microplates (standard or deep well) |
| Ambient Operating Temperature | 0–65 °C |
| Operating Humidity | Up to 100% |
| Dimensions | 11.9 × 13.4 × 3.5 in (30 × 34 × 9 cm) |
| Weight | 25 lb (11.5 kg) |
| Cord Length | 60.5 in (154 cm) |
| Electrical | 115 V (BT4500); 230 V (BT4500-E); 50–60 Hz |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| BT4500 | 115V, US plug |
| BT4500-E | 230V, European plug |
