The BioClave 28 is a benchtop research autoclave with a 28 L stainless steel chamber for liquids, media, glassware, plasticware and instruments. Pressing start runs the full fill, sterilize, exhaust and dry cycle from a built-in water tank, with no external water connection, at up to 34.8 PSI (2.4 bar). Preset programs cover liquids, wrapped instruments and unwrapped instruments or plasticware, a Dry Only option extends drying, and every parameter can be adjusted. A mechanical and electrical interlock keeps the door closed until pressure reaches zero.
Key features
- 28 L stainless steel chamber, 34.8 PSI (2.4 bar) maximum pressure
- One-button automatic fill, sterilize, exhaust and dry cycle
- Built-in water tank; no external water connection
- Door interlock holds until chamber pressure reads zero PSI
- USB drive records settings; optional thermal mini-printer for cycle records
- 120V (B4000-28-120) or 208–240V (B4000-28-220); 2,300W, 209 lb
Specifications
| Brand | Benchmark Scientific |
|---|---|
| Chamber Volume | 28 L |
| Max Pressure | 34.8 PSI (2.4 bar) |
| Cycles | Preset liquids, wrapped instruments, unwrapped instruments/plasticware; Dry Only; fully adjustable |
| Operation | Fully automatic fill, sterilize, exhaust and dry |
| Water Supply | Built-in water tank; no external connection |
| Safety | Mechanical and electrical door interlock |
| Chamber | Stainless steel |
| Weight | 209 lb (95 kg) |
| Electrical | 120 V, 50–60 Hz (B4000-28-120); 208–240 V, 50–60 Hz (B4000-28-220) |
| Power | 2,300 W |
| Warranty | 1 year |
Ordering information
| Catalog number | Power |
|---|---|
| B4000-28-120 | 120V |
| B4000-28-220 | 208–240V |
