The W3300-1200 is an Accuris compact balance for weighing up to 1,200 g at 0.1 g readability. It has no draft shield and uses a larger 16 cm (6.3 in) round pan. The gold-plated ceramic capacitor sensor feeds a large backlit LCD, and the splash-resistant control panel switches between grams, ounces and carats and runs piece counting and percent programs. Calibration is external; the recommended weight is the W1005-1000 1 kg. An RS232 port outputs results to a computer or printer.
Key features
- 1,200 g capacity, 0.1 g readability
- 16 cm (6.3 in) round pan, open design without draft shield
- Gold-plated ceramic capacitor weighing sensor
- Counting and percent programs; g, oz, ct
- Calibrate with W1005-1000 (1 kg) weight
- RS232 port for printer or computer
Specifications
| Brand | Accuris |
|---|---|
| Catalog number | W3300-1200 / W3300-1200-E |
| Capacity | 1,200 g |
| Readability | 0.1 g |
| Linearity | ±0.2 g |
| Pan Diameter | 6.3 in (16 cm) |
| Draft Shield | None |
| Calibration | External |
| Recommended Calibration Weight | 1 kg |
| Weighing Units | g, oz, ct, pieces, % |
| Display | Backlit LCD |
| Connectivity | RS232 |
| Electrical | 115 V, US plug (W3300-1200); 230 V, European plug (W3300-1200-E) |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| W3300-1200 | 115V, US plug |
| W3300-1200-E | 230V, European plug |
