The W3300-10K is the highest-capacity Accuris compact balance, weighing up to 10,000 g with 0.1 g readability. Its 7 in (18 cm) round pan is open, without a draft shield ring, and the body stays compact at 18.8 × 28 × 8 cm. Weight is sensed by gold-plated ceramic capacitors and shown on a large backlit LCD. The splash-resistant panel selects g, oz or ct and runs piece-counting and percent programs. Calibration is external with the recommended W1005-2000 2 kg weight, and RS232 sends data to a computer or printer.
Key features
- 10,000 g capacity, 0.1 g readability
- 7 in (18 cm) open round pan
- Compact 7.5 × 11 × 3.1 in housing
- Piece counting and percent weighing; g, oz, ct
- Uses W1005-2000 (2 kg) for external calibration
- RS232 connection to a computer or printer
Specifications
| Brand | Accuris |
|---|---|
| Catalog number | W3300-10K / W3300-10K-E |
| Capacity | 10,000 g |
| Readability | 0.1 g |
| Linearity | ±0.2 g |
| Pan Diameter | 7 in (18 cm) |
| Draft Shield | None |
| Calibration | External |
| Recommended Calibration Weight | 2 kg |
| Weighing Units | g, oz, ct, pieces, % |
| Display | Backlit LCD |
| Connectivity | RS232 |
| Dimensions | 7.5 × 11 × 3.1 in (18.8 × 28 × 8 cm) |
| Electrical | 115 V, US plug (W3300-10K); 230 V, European plug (W3300-10K-E) |
| Warranty | 2 years |
Ordering information
| Catalog number | Power |
|---|---|
| W3300-10K | 115V, US plug |
| W3300-10K-E | 230V, European plug |
