Hotplate Stirrer, LED Digital 7x7

Product Description The SCILOGEX SCI550-S provides powerful heating and stirring with LED digital display of the set temperature and real-time temperature display. LED heating and analog stirring are simply controlled turning the respective control knobs. Product Features ❖ LED display for precise monitoring of temperature ❖ A wide speed range of 50 to 1500rpm ❖ Heat only, stir only or heat and stir together functions ❖ Max. Heating plate temperature 550°C ❖ Low temperature stability ❖ Electronic speed control for constant speed even during changes in load ❖ External temperature control is possible by connecting the temperature sensor(PT1000) with accuracy at ±0.2°C ❖ High magnetic adhesion ❖ HOT warning will flash if the work plate temperature is above 50°C even when the hotplate is turned off ❖ cTUVus approved for UL and CSA ❖ 2 YEAR WARRANTY Product Specifications Work plate dimension[W x D] 184x184mm(7 inch) Work plate material Glass ceramic Motor type Shaded pole motor Motor input power 15W Motor output power 1.5W Power 1030W Heating output 1000W Voltage 110V, 60Hz Stirring positions 1 Max. stirring quantity[H2O] 10L Max. magnetic bar[length] 80mm Speed range 200-1500rpm Speed display Scale Temperature display LED Heating temperature range Room Temp.-550°C, increment 5°C Temperature control accuracy ±10°C Overheating protection 580°C Overheating protection ±0.1°C External temperature sensor PT1000 (accuracy ±0.2) “Hot” warning 50°C Protection class IP21 Dimension[WxDxH] 215x360x112mm Weight 4.5kg Permissible ambient temperature and humidity 5-40°C, 80%RH
